China Digital Cable HD H 264 Set Top Box Russia Mini Setup Box Plastic Case Material for sale

Digital Cable HD H 264 Set Top Box Russia Mini Setup Box Plastic Case Material

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: Negotiable

Brand: JIZHONG

Product Description

Digital Cable HD H.264/MPEG-4/MPEG-2 Set Top Box Russia Mini TV Box

Main Features

Support multiple star QAM modulation.(16/32/64/128/256QAM)
Support Dexin/Sumavision/CTI CA conditional receive system.
Support EPG and program reservation management and EPG advertisement business
Support mainstream middle ware ,bidirectional browser and information customization service.
Support PVR reservation and real time recording and encoder application
Built in player,support USB local video/music/picture player
Support loader air upgrading manual,automatic and USB etc.Its able to upgrade to latest version in time.
Adopt advanced QAM demodulation/MPEG-2/MPEG-4/H.264/AVS+ decode technology,which able to receive and decode digital TV program from DVB/MPEG/H.264/AVS/AVS+ compatible with CATV network.
Support multiple conditional Access system encoder way.EPG and advertisement business.
Support PVR reservation,record and decode function.
Simple and straightforward operation interface,variety program
High efficient user experience,brings more convenience and humanization
Completely meet the standard of DVB-C/MPEG-2/4/H.264/AVS/AVS+

Menu

Technical Parameters

I.General
STB TYPE	Digital Cable HD H.264/MPEG-4/MPEG-2 Set Top Box Multi Language Mini TV Box
Main Chipset	Montage M88CC6000
Mechanical	Plastic
Function/Interface	RS232,HDMI1.3B(support HDCP),USB2.0,IR LOOP OUT3.5mm,DC12V/0.8A
Conditional Access	Dexin
POWER SUPPLY TYPE	External power adaptor ,DC12V 0.8A output
II.Software Features
Decoding Standard	DVB-C/MPEG2/4,H.264/AVS/AVS+
QAM Modulation	16/32/64/128/256QAM
CA	Dexin,Sumavision,ABV,STV,Irdeto
PVR	Support PVR reservation and real-time recording and encryption application
Menu	Friendly interface menu
Multi language	Supports menu language in English & other necessary language
Channel Edit	Various channel editing function(favorite,add,delete and parental look)
Channel search	Auto scan,manual scan
Software upgrade	software upgrades by USB,and loader air upgrade manually and automatically.
Sorting	Sort channel and display channel list on basis of channel content
Multi Media	Supports video&music playing,image browsing via USB 2.0
EPG	7-day electronic program guide
Channel Saving	Automatically save the channel being watched before power failure
1.CPU processor and memory
CPU processor speed	@700MHz
Flash	8 MByte
RAM Memory	128 MByte
2.Tuner
Frequency Range	47-862MHz
Input Impedance	75Ω
Input level range	-20 to 20 dBmV 64QAM/-19 to 25 dBmV(256QAM)
3.Demodulator & Channel Decoder
Standard followed	DVB-C EN300 429
Demodulation	16QAM,32QAM,64QAM,128QAM,256QAM
Symbol Rate	3.6 - 6.952MS/s
4.Video Decoding
Video Decode	MPEG-2MP@ML/MPEG-4SP@ASP/H.263/H.264/AVS/AVS+/Xvid/VC-1/WMV9/VP8
Aspect Ratio	4:3,16:9
Video Resolution	1920*1080MAX
5.Audio Decoding
Audio Decode	MPEG-1Layer1&2/MPEG-2/AAC/AC3/RA/WMA/Dolby Digital Plus
Sound Mode	left/right/Stereo
6.Environment
Power supply Unit	External power adaptor,100-240v input,DC12V 1A output
Power consumption	≤ 10W
Operating Temperature	0 ℃ to 50℃
Storage Temperature	-20℃ to 60℃
Humidity	<95%
Mechanical
STB CASE	PLASTIC
STB Dimension	11211224(MM)
STB Accessories
RCU	1*RCU
Power Adaptor	1*External Power adaptor
User Manual	1*Single sheet user manual
HDMI Cable	1*HDMI Cable
A/V cable	1*A/V cable
