1550nm 2 Distribute Output Ftth Micro Node With WDM AGC 100*105*27mm
Price:
Negotiable
MOQ:
1pc
Delivery Time:
Depends
Brand:
JIZHONG
Product Description
1550nm 2 Distribute Output Optical Fiber Receiver With WDM For FTTH Network
FEATURES
- Compact size,easy for installation.
- Adopt single fiber,built in WDM.
- Adopt low noise technology,with AGC function.
- Led display working status
- With external power adapter.
Technical Specification
| Item | Unit | Specification |
| Keywords | 1550nm 2 Distribute Output Optical Fiber Receiver With WDM For FTTH Network | |
| working bandwidth | MHz | 47 - 1000 |
| Nominal input power | dBm | -15~-5 |
| RF Flatness in Band | dB | ±1 |
| Output reflection loss | dB | ≥16(45~550MHz) / |
| ≥14(550~862MHz/1000MHz) | ||
| Link C/N | dB | ≥48 |
| Link C/CSO | dB | ≥65 |
| Link C/CTB | dB | ≥ 65 |
| Output level | dBμV | 2 way distribution 75 |
| Power adapter | V | 12V/1A |
| Power consumption | W | 4.7 |
| Dimension | Mm | 100*105*27 |
| Application | ||
 |
||
