Single Fiber Mode 1 GE EPON ONU / 2 PORT OLT 1 GE+1 FE EPON 1.25Gbps

Price Negotiable

Price: Negotiable

MOQ: 1pcs

Delivery Time: 5 work days

Brand: JiZhong

Product Description

FTTH ONU Device PON EPON ONU OLT 2 PORT 1 GE+1 FE EPON 1.25Gbps

Products Features:

xPON adaptive GPON and EPON mode supported

Protocol: GPON- G.984/ G.983 code ; EPON- 802.3-2005/CTC support G.711, G.722, G.729 and T.38 coding and encoding protocol

support VoIP, wifi bgn or CATV(see detailed model function)

support L2/L3 multicast forwardingL2 bridge forwarding,L3 router forwarding,NAT/NAPT

support flexible traffic classification;

support HQoS (Hiberarchy Quality of Service)

Data Process:

Support two-way linear speed data forwarding, support 256 MAC Address Table

Support 802.3 SNAP and Ethernet II package, supporting 802.1P/Q priority definition, IP DSCP field, ACL definition based priority

Support tag identification,modify and add; support protocol message identify and capture

Supports ACL rule(supporting MAC/IP/TCP/UDP/ICMP /IGMP /IPv6 format )

Ethernet support adaptive or manual rate and full/half duplex

Support 802.1x certificate, STP /RSTP protocol

Traffic control based on ingress ; support QoS function

DataSheet:

Connector type	SC/PC
PON No.	1
Fiber mode	Single fiber
Wavelength	Transmitting port:1310 +/-20nm, Receiving port:1490 +/-10nm
Portocol	GPON: ITU-T G.984.1/2/3/4; EPON: 802.3-2005 and CTC EPON
Speed	GPON: download 2.488Gbit/s, upload 1.244Gbit/s;
	EPON: symmetric 1Gbit/s
Output optical power	Min. 0dBm; max. +4dBm
Receiver sensitivity	Better than -27dBm
Receiver optical power	Min. -3dBm
Damaged threshold value	7dBm
Optical link length	Max. 20km
CATV optical receiver index and parameters
Optical part
Optical wavelegth	1200~1650nm
Receiving optical power	0
Reflection loss	≥50dB
Optical connector	FC/APC
Fiber mode	Single fiber or Double fiber
Isolation (WDM)	Forward path≥40dB,Reflection path≥22dB
