Customized 2 Ports Fiber Optic Equipment 2FE EPON FTTH ONT Modem

Price Negotiable

Price: Negotiable

MOQ: 1pcs

Delivery Time: 5 work days

Brand: JiZhong

Product Description

Customized 2 Ports Fiber Equipment Modem FTTH ONT 2FE EPON FTTH ONU

Data Process:

Support two-way linear speed data forwarding, support 256 MAC Address Table;

Support 802.3 SNAP and Ethernet II package, supporting 802.1P/Q priority definition, IP DSCP field, ACL definition based priority

Support tag identification,modify and add; support protocol message identify and capture

Supports ACL rule(supporting MAC/IP/TCP/UDP/ICMP /IGMP /IPv6 format )

Ethernet support adaptive or manual rate and full/half duplex

Support 802.1x certificate, STP /RSTP protocol

Traffic control based on ingress ; support QoS function

Technical Index:

Hardcase

Shell	Plastic casing		Operating temperature: 0 to 50ºC

Physical	Item Dimension:	Working	Storage temperature: -40 to 85ºC
		Enviornment
weight	0.2kg/pc	Enviornment	Operating humidity: 10% to 90%(Non-condensing)

indicator	Power/PON/LOS/LAN		Storage humidity: 10% to 90%(Non-condensing)

Port Datasheet
	Wavelength: Tx 1310nm, Rx1490nm		VLAN Tag/UNTAG

	Tx Optical Power: 0~4dBm		Q in Q VLAN

PON	Rx Sensitivity: -27dBm	Ethernet	MAC address restricion
Parameter	Two direction FEC(Forward Error	Ethernet	MAC address learning
Parameter	Two direction FEC(Forward Error		MAC address learning

	authertation: MAC/Key/LOID		two layer IPv6 transparent transmit

	Optical Fiber: 9/125 single-mode fiber		1:1 VLAN/N: 1VLAN/VLAN transparent transmit

Function
	Ethernet speed limitation		OMCI/Web UI
	Support VLAN TAG/UNTAG,VLAN		802.1ag Ethernet OAM
	conversion		802.1ag Ethernet OAM
	conversion
QoS	Support Port-based speed limitation		loop detection
	802.1p Priority	O&M	optical link supervision
	broadcast storm control		IGMP v2/v3 snooping
	flow mapping		MLD v1/v2 snooping
Security	MAC address filter		downstream VLAN switch/ transparent transmit

Operation	PPPOE/DHCP proxy test		IGMP/MLD message speed limitation
