1200~1600nm Wavelength Outdoor Optical Node 2 Way Optical Receiver With AGC

Price Negotiable

Price: Negotiable

MOQ: 1pcs

Delivery Time: 5 work days

Brand: JiZhong

Product Description

CATV 4 Output Outdoor Optical Node CATV Two Way Optical Receiver With AGC

Model NO:JZOR1000RII-4AV

Performance characteristics:

1. 5~1000MHz optimized circuit design;

2. High responsivity PIN receiving. Digital tube displays input optical power;

3. GaAs power amplification technology, make Link path good C/N, C/CSO, C/CTB index. each power increasing module push 2 way downlink output, output capacity is 108dBuV;

4.each port is divided with independant bi-directional filter, each way reverse signal can be adjusted independantly;

5. Support network management function, Type-II network management transponder;

Technical Parameters:

Items	Unit	Technical Parameters
Donwlink working bandwidth	MHz	47~1000
Optical AGC range	dBm	-8~+2
Optical working wavelength	nm	1200~1600
RF in band flatness	dB	±0.75
Output reflection loss	dB	≥16(47~550MHz) ≥14(550~862MHz)
Link C/N	dB	>51
Link C/CSO	dB	>60
Link C/CTB	dB	>65
Output level	dBuv	104
Uplink working bandwidth	MHz	5~65
Uplink output optical power	mW	0.5~4
NPR	dB	≥20(DFB laser) ≥15(FP laser) (NPR≥30dB) (NPR≥30dB)
Power consumption	W	≤30
Size	mm	330x220x130
