Muni Pack Gravel Pack Screen Tube Cylinder Sahpe For Water Well ISO Listed
Stainless Steel 304 Muni Pack Water Well Screens
Company Profile:
Oasis is a famous manufacturer which integrates the research and development, design, manufacture and sell water well screens/johnson screens/wedge wire screen/rod base screen/continuous slot screen/non-inforced Johnson screen, oil well screens and sand control well screens, bridge slotted well screens, pipe based well screens/perforated base pipe with screen jacket/pipe base screen/reinforced Johnson type screen, perforated pipe (base pipe), gravel pre-packed well screens, passive water intake screens etc. water, oil and gas well filtering products as well as API/Stainless Steel Casing& Tubing and pipes and industrial parts.
Muni Pack Screens is the improvement of gravel packed screens.
It consists of two screens or multilayer screens and the stuffing between the screens. Perforated pipe/Johnson screens inside and Johnson type screens/wedge wire screens outside.The base pipe can be made of casing pipes, seamless pipe or welded pipe.
If Muni pack screens consists of inside and outside screens, the collape strength is strong than single screens.
Characteristics of Muni Pack Screens
1. Gravel pre-packed stainless steel casing screens consist of two layer screens.
2. The screen jacket and base pipe are welded together with a length of coupling.
3. The inside screen can have different slots.
4. The filler can be gravel,sand or ceramic balls.
Single screens |
MUTI screen |
Single screens |
MUTI screen |
Single screens |
MUTI screen |
||
| 2 | 2×4 | 1940 | 16500 | 4300 | 12500 | ||
| 3 | 3×5 | 540 | 5650 | 5200 | 15000 | ||
| 4 | 4×6 | 730 | 2830 | 6100 | 18800 | ||
| 5 | 5×7 | 440 | 1550 | 7000 | 20700 | ||
| 6 | 6×8 | 260 | 990 | 17600 | 41600 | ||
| 8 | 8×10 | 250 | 1160 | 24200 | 50000 | ||
| 10 | 10×12 | 360 | 630 | 30800 | 81400 | ||
| 12 | 12×15 | 220 | 880 | 35200 | 87000 | ||
| 14 | 14×16 | 170 | 1110 | 35200 | 95400 | ||
| 16 | 16×18 | 170 | 760 | 72200 | 135900 | ||
| 18 | 18×20 | 130 | 540 | 74200 | 147200 | ||
Pictures of muni pack screen:
Perforated Base Pipe:
Screen Jacket:
Our certificate:
FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory, located on Xuanhe West Road, Xinxiang city, Henan Province, China
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free but freight by customer, and this fees will repay to you when the order be placed in the future.
Q: What is your terms of payment ?
A: Below10000USD paid by TT in advance, more than 10000USD, TT and LC are accepted.
