7 " 177mm Slotted Stormwater Pipe , BTC Ends R3 Unit Length Water Well Screen Pipe
7 " 177mm Of N80 L80 Slotted Liner With BTC Ends R3 Unit Length
Company information:
Oasis located in the industrial park of high-tech enterprises in Fengquan District, Xinxiang City, covers more than 20000 square meters with total RMB 15 million investment. Oasis now has more than 150 staff, among them 6 persons are senior engineer. Since founded, OASIS always adhere to the “development on innovation, development on efficiency and treat customers with honesty” business philosophy. Now OASIS has developed into a famous manufacturer which integrates the research and development, design, manufacture and sell water well screens/johnson screens, oil well screens and sand control well screens, bridge slotted well screens, pipe based well screens, perforated pipe (base pipe), gravel pre-packed well screens, wedge wire screens, passive water intake screens etc. water, oil and gas well filtering products as well steel tubes and pipes and industrial parts.
7" N80 BTC R3 Slotted Casing Liner:
The controlling of slotted casing liner for water well drilling according to the specifications and Machining parameters of the pipe body. When the pipe is under slotting , the procedure including: surface treatment of the pipe before process, cooling and eliminating the heat during the whole slotting as well as removing the iron rust and oxide; make quality inspection after the slotting of the pipe and the substandard pipes be sent to the waste collecting station.;marking the pipes fits for the requirement of the quality; issuing the material certificate and delivering the goods.
|
API Std.Casing |
ID (mm) |
Length (mm) |
Slot Length (mm) |
Slot No./m |
Slot Width (mm) |
Slot Tolerance |
Valid Filter Area (cm2/m) |
Max. Strength (kn) |
||
|
Spec. (mm) |
Thickness (mm) |
Per Weight (mm) |
||||||||
|
60.32 |
5 |
6.84 |
50.3 |
3 |
80 |
200 |
0.3 |
±50 |
48 |
512.54 |
|
73.02 |
5.5 |
9.15 |
62 |
3 |
80 |
240 |
0.3 |
±50 |
57.6 |
688.55 |
|
88.9 |
6.5 |
13.22 |
75.9 |
3 |
80 |
280 |
0.3 |
±50 |
67.2 |
995.1 |
|
101.6 |
6.5 |
15.22 |
88.6 |
3 |
80 |
300 |
0.3 |
±50 |
72 |
1151.2 |
|
114.3 |
7 |
18.47 |
100.3 |
10 |
80 |
320 |
0.3 |
±50 |
76.8 |
1400.4 |
|
127 |
7.52 |
22.13 |
112 |
10 |
80 |
340 |
0.3 |
±50 |
81.6 |
1673.8 |
|
139.7 |
7.72 |
25.11 |
124.3 |
10 |
80 |
360 |
0.3 |
±50 |
86.4 |
1900.2 |
|
9.17 |
29.48 |
121.4 |
10 |
80 |
360 |
0.3 |
±50 |
86.4 |
2232.4 |
|
|
168.3 |
8.94 |
35.09 |
150.4 |
10 |
80 |
400 |
0.3 |
±50 |
96 |
2672.95 |
|
177.8 |
8.05 |
33.68 |
161.7 |
10 |
80 |
440 |
0.3 |
±50 |
105.6 |
2559.2 |
|
9.19 |
38.19 |
159.4 |
10 |
80 |
440 |
0.3 |
±50 |
105.6 |
2940.7 |
|
Product performance:
1. Our slot pipe use J55/K55/N80 casing and tubings of API standard, with High overall strength, not so easy to deformation.
2. The edge of the slot is vertical, smooth, without burrs, and the slot is uniformity.
3. The slot casing liner is suitable for sandy well, which the diameter of the sand greater than 0.3mm.
4. The slot can be longitudinal and transverse, the section of the slot can be parallel and trapezoidal types, with a wide open area.
5. Casing slotted liner has a big inner diameter.
Packing details:
Single with bubble bag and then in wooden case(fumigation certificate).
ISO 9001:2008 CERTIFICATE:
Why choose us OASIS slotted casing liners?
. World Class Quality
. Third party inspection
. Non Standard Screens
. Quick Delivery
. Lower Maintenance of the well
. Environmentally safe
