Drone detector 5km Detection Radius 700-6300MHz Wideband 360° Omni-Directional for UAV Early Warning
700-6300MHz Wideband 5km Long-Range Drone Detector
This detector boasts an impressive 5km detection range—far exceeding standard consumer-grade detectors. Whether in open fields, industrial complexes, or large event venues, it can identify approaching drones at an early stage, providing ample time for security personnel to assess the situation, issue alerts, and take response measures.
Our detector addresses this by covering an extensive frequency spectrum of 700-6300MHz—a range that encompasses most common drone communication and control bands. This product features 360° omni-directional detection capability. Its specially designed antenna array ensures uniform signal reception across all angles.
Features
- 700-6300MHz full air space detection
- Detecting distance around 5km(Increasing antenna gain can extend the detection distance)
- Can extract drone signals under noise interference level (SNR -10 ~ -15dB)
- Analysis DJI FPV date Including pilot location, blacklist and whitelist,connect to Bluetooth to update the firmware
- Provide FPV drone video image output,connect to Bluetooth to update the firmware
Function introduction
| Drone detection | It can scan, receive and identify common civilian drone image transmission signals, demodulate parameters of signals that meet certain characteristics, and send warning data to the host computer. |
| Black and White List | Accurately identify drone models and unique electronic fingerprints to achieve a black-and-white list, and simultaneously identify ID≥ 220 |
| Expand multi band strike | Capable of expanding the interference capability of multiple frequency bands, covering the vast majority of drones on the market |
| Networking | The system can network multiple devices through a cloud server, which can observe the online/abnormal status of each device. It can remotely control the device through a mobile terminal (mobile IPAD), including but not limited to viewing the device system operation interface, receiving alarm information, viewing black and white lists, and update online functions |
| Omnidirectional detection | The product has the ability to handle horizontal 360 ° omnidirectional interference |
| Portability | Installed with fixed poles and tripods, it can meet the protection needs of long-term deployment in key areas; Can also use a tripod to quickly erect to meet the protection needs of temporary tasks such as important meetings and group activities |
| Safety | With user management function, divided into administrators and users, and encrypting data to ensure user data security. |
Technical Indicators
| Regular detection range | 5km(Good radio environment) |
| Detection frequency bands | 0.7-6.3GHz/ 2.4-2.5GHz/5.15-5.95GHz |
| Identify Type |
FPV Simulation Image Transmission OFDM HD Image Transmission |
| Detection angle | 360° |
| Sensitivity |
Better than -96dBm (FPV signal Bw=6MHz) Better than -90dBm (OFDM signal Bw=20MHz) |
| Detection distance |
＞2km (OFDM) ＞4km (FPV 5.8G/2W) (The measured reliable distance when using a 2dBi gain receiving antenna. The actual antenna gain increases by 6dB, and the detection distance can be doubled.) |
| UART Parameters | 115.2kbps/TTL3~5V compatible |
| Power supply | DC 4.75 ~36V |
| Power consumption | ＜3.5W |
| Weight | 25kg |
| Volume | 330mm x 330mm x 330mm |
| Protection grade | IP65 |
| Working temp | -40 ~ +70℃ |
Application
It is used to cooperate with the portable drone interference setting to compensate for the untimely detection of drones during work; It is used for mobile duty of police personnel and vehicles, and detects surrounding drones as soon as possible.By locating the position of drone pilots, we can effectively combat illegal flying. By analyzing DJI drone data, we can better deal with jamming drones.
