Inverter Plastic Washing Recycling Machine , 12-14mm PET Flakes Hot Washing Machine

Plastic PET bottle recycling line/waste recycling machine for PET bottle

• This recycling/washing line is mainly used to recycling the waste PET bottles, water bottles, cola bottles, PET
sheet and PET packing containers.
• The whole line includes: conveyor belt, label remover(dry type or water type), sorting system,metal detecting system, plastic granulator or crusher, sink-float washing tank, hot washing system, frication washer, dewatering machine, thermal dryer, label/dust/fin separator and packing system.
• The above machines can easily remove the labels, caps, rings, glue, dirties and other impurities, finally you will get ideal PET flakes.
• All your requirements of the washing line will be customized.

Flowchart:

Conveyor belt →Label remover machine → Sorting table→Conveyor belt → Crusher  → Screw loader→ Float washing tank→ Friction washing machine → Screw loader→Hot washer tank → High-speed friction washing machine → Floating washing tank → Dewatering machine → hot air dryer system → zig zag air classifier system → Silo

Features:
• Labor saving. The bale opening and feeding system we provide will equally feed the material.
• You can use the manually sorting system to selecting out different color bottles and non-PET material
• Metal detector is optional for you which used to take out any kind of metal from the PET bottles
• Specially designed PET bottle granulator can easily get high output and with water doing wet griding can
reduce wear of blades.
• High speed dewatering machine and drying system will insure the final PET flakes moisture <1%
• The Fin dust separator machine will remove the final labels from the flakes to guarantee the PVC content

Application:
• The PET Bottle Washing Machine is specially designed to produce fiber use PET flakes.
• The flakes can be used for the 2-D, 3-D PSF, filament yarn, PET strap, PET sheet or PET film.
• The PET Bottle Washing Machine can adopt the PLC automatic control of the full line to control the final products quality and save energy.
• It can be equipped with the Europe automatic material sorting system and color sorting system.
• It can be customized according to the raw material and customer requirement.

Technical dates:
