Single Shaft Waste Plastic Lumps Shredder Machine 200kg/H Granulator
Price:
$10,000.00/sets >=1 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
MOOGE TECH
Product Description
Waste Plastic Lump Shreddering / Single Shaft Shredder Machine
Products Description
Plastic shredder/shredding machine was main used to shred different kinds of plastic materials, especially very large waste plastic.
single shaft shredder machine can shredding plastic lumps, barrels, pipes , wood, wood pallet, big block material, plastic container, plastic chair , plastic pallet, woven bags ,jumbo bags, cable tc.
Our company has many years experience in manufacturing the plastic shredder machine, we supply 300~2000 kg/h capacity . we also can make it according to your requirement.
Shredder machine advance 1. It adopts PLC control system, automatic overload protection and auto reverse switch 2. Good shaft structure design, low noise, blades easy changeable 3. The low rotation speed results in a particularly quiet shredding process with low levels of dust generation 4. It can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc.
Product Paramenters
|
Model
|
VS-2860
|
VS-4080
|
VS-40100
|
VS-40120
|
VS-40150
|
VS-48150
|
|
Motor
|
22KW
|
37KW
|
45KW
|
55KW
|
75KW
|
90KW
|
|
Rotor speed
|
83 RPM
|
83 RPM
|
83 RPM
|
83 RPM
|
83 RPM
|
83 RPM
|
|
Rotor Diameter
|
280 mm
|
400 mm
|
400 mm
|
400 mm
|
400 mm
|
480 mm
|
|
Rotor Blade Qty
|
26 PCS
|
38 PCS
|
46 PCS
|
58 PCS
|
74 PCS
|
111 PCS
|
|
Fixed blade Qty
|
1 PCS
|
2 PCS
|
2 PCS
|
2 PCS
|
3 PCS
|
3 PCS
|
|
Screen diameter
|
60mm
|
60mm
|
60mm
|
60mm
|
60mm
|
60mm
|
|
Capacity
|
300 kg/h
|
600 kg/h
|
800 kg/h
|
1000 kg/h
|
1500 kg/h
|
2000 kg/h
|
Product Photos
Rotary shaft
The rotary shaft made by high quality carbon steel,anti-worn
Rotary blade
Move blade made by D-2, by bolt fixed in the rotor shaft ,it is easy for worker change it . blade can use 4 times when the blade worn after using long time
Fixed Blade
Using D-2 materail,USA Standard,HRC 58-59 more better than SKD-II,We also can use DC-53 material
Screen
the screen use 10mm thickness carbon steel made,with 60mm screen,the flakes will easy shredding and down
Motor
Using Beide brand motor(siemens standard motors ltd in china)
Bearing
Using Japan famous brand- NSK
original import from Japan factory
We also supply SKF bearing for customer
Contactor
Use Schneider brand in us control system
PLC
Use Siemens PLC for shredder machine
Automatic control rotor shaft postive , negative rotary
Before shredding(Raw materail)
After shredding(Plastic flakes)
Auxiliary Machine
Double shaft shredder machine
Heavy duty Single shaft shredder machine
S Model Plastic crusher machine
PC Model Plastic crusher machine
Packing & Delivery
After Sales Service
Before Sales Service
1. 24 hours online. Your inquiry will be quick reply by email. Also can go through all questions with you by any online chatting tools (Wechat, Whatsapp, Skype, Viber, QQ, TradeManager ) 2. Professionally and patiently introduction, details pictures and working video to show machine
On Sales Service
1. Test every machine and inspect the machine seriously. 2. Send the machine picture which you order, then packing it with standard export wooden box after you confirm the machine is ok. 3. Delivery: If ship by sea .after delivery to seaport. Will tell you the shipping time and arrival time. Finally, send all original documents to you by Express For Free. If delivery it by Express to your door (DHL, TNT, Fedex, etc) or by air to your airport, Or logistic to the warehouse which you request. We will tell you the tracking number after delivery.
After Sales Service
1. Free insurance for goods 2. 24 hours online to solve any problem. Supply you English manual book and technical support, maintain and install video to help you solve the problem, or dispatch worker to your factory.
