1) Rated voltage: 300/600V;
2) Insulation Resistance: 200MΩ·km
3) Ambient Temperature: -20℃~75℃
4) Installation Temperature: -5℃~60℃
SPT-1 | |||||||||||||
Size Range mm2 (AWG) | 0.519 (20) | 0.824 (18) | |||||||||||
Norminal Insulation Thickness mm | 0.76 | 0.76 | |||||||||||
Number of Cores | 2 or 3 | ||||||||||||
SPT-2 | |||||||||||||
Size Range mm2 (AWG) | 0.824 (18) | 1.04 (17) | 1.31 (16) | 2.08 (14) | |||||||||
Norminal Insulation Thickness mm | 1.14 | 1.14 | 1.14 | 1.14 | |||||||||
Number of Cores | 2 or 3 | ||||||||||||
SPT-3 | |||||||||||||
Size Range mm2 (AWG) | 0.824 (18) | 1.04 (17) | 1.31 (16) | 1.65 (15) | 2.08 (14) | 3.31 (12) | 5.26 (10) | ||||||
Norminal Insulation Thickness mm | 1.52 | 1.52 | 1.52 | 1.52 | 2.03 | 2.41 | 2.79 | ||||||
Number of Cores | 2 or 3 | ||||||||||||
Type | AWG/No.of cores | NO./Normal Diameter of strand(mm) | Normal Thickness of Insulation(mm) | Over Diameter of Cable(mm) |
SPT-1 | 20 x 2C | 26/0.16 | 0.76 | 2.55 x 5.1 |
18 x 2C | 41/0.16 | 0.76 | 2.7 x 5.4 | |
18 x 3C | 41/0.16 | 0.76 | 2.7 x 8.0 | |
SPT-2 | 18 x 2C | 41/0.16 | 1.14 | 3.4 x 6.8 |
16 x 2C | 65/0.16 | 1.14 | 3.7 x 7.4 | |
18 x 3C | 41/0.16 | 1.14 | 3.5 x 8.6 | |
16 x 3C | 65/0.16 | 1.14 | 3.8 x 9.6 | |
SPT-3 | 18 x 2C | 41/0.16 | 1.52 | 4.4 x 8.7 |
16 x 2C | 65/0.16 | 1.52 | 4.8 x 9.5 | |
14 x 2C | 41/0.254 | 2.03 | 6.0 x 12.0 | |
12 x 2C | 65/0.254 | 2.41 | 7.4 x14.0 | |
10 x 2C | 105/0.254 | 2.79 | 9.1x18.2 | |
18 x 3C | 41/0.16 | 1.52 | 4.4 x 10.7 | |
16 x 3C | 65/0.16 | 1.52 | 4.8 x 11.8 | |
14 x 3C | 41/0.254 | 2.03 | 6.0 x 14.5 | |
12 x 3C | 65/0.254 | 2.41 | 7.4x16.5 | |
10 x 3C | 105/0.254 | 2.79 | 9.1 x 18.8 |
