Water Well Drill Rig Lifting Force 60T Well Drilling Rig Crawler Water Well Drilling Equipment

Name: Water Well Drill Rig Lifting Force 60T Well Drilling Rig Crawler Water Well Drilling Equipment
Brand: Quzhou Sanrock Heavy Industry Machinery Co., Ltd.

Price Negotiable

Price: negotiable

MOQ: 1Set/Sets per Month

Delivery Time: 15-30days

Brand: SANROCK

Product Description

This series of water well drilling machine has the characteristics of standardized configuration, compact and reasonable structure, fast drilling speed, economical and durable, low failure rate, etc. It has been recognized by the market once it is launched, and has been widely used in mining engineering construction, civil drilling, geothermal drilling and other fields. They are widely used in industrial and agriculture water project, testing well and other exploration borehole. In particular, drilling hole for geothermal heating, it can also meet the engineering basis for reinforcement, loose gravel drilling rock formation connected with a variety of engineering. Our drilling rigs are more efficiency and with low failure rate, more economic and durable, and with a high comprehensive cost performance.

In particular, it solves the difficulty in drilling the soil layer with air DTH hammer, and the construction problem of the rotary drilling rig in the hard rock layer, gravel and pebble layer. It can work efficiently under various geological structures and realize the perfect combination of water drilling and air drilling.


Feature:

The drilling footage is fast and efficient. The automobile chassis is adopted,the layout is reasonable and compact, and the operation is simple.

Equipped with hydraulic outriggers for leveling the rig and keeping the machine stable. The main engine is equipped with a high-power diesel engine with strong power to meet work needs.

Equipped with hydraulic lifting and lowering composite drill boom, which saves space and provides powerful lifting force for deep hole operations.

The drilling rig is equipped with a hydraulic feed system, dual hydraulic motor power heads, chain transmission and hydraulic cylinder propulsion, with large torque and high drilling efficiency.

Equipped with quick rod unloading device, which can quickly disassemble the drill rod, saving time and effort.

Centralized operating handles, reasonable layout, safe and feasible. Excellent workmanship, durable, and low maintenance costs.

Centralized control console is suitable for each manipulation and control.

Rapid pulling and enhance the work efficiency.

Products Description

Product name	Water Well Drilling Rig
Model	Unit	SR1200S
Max drilling depth	M	1200
Drilling diameter	mm	105-900
Engine brand	/	Weichai
Power	kw	263
Rotary motor brand	/	Danfoss
Pump brand	/	Permco
Air pressure	Mpa	1.65-8
Air consumption	m³/min	16-120
Drill pipe length	m	6
Drill pipe diameter	mm	127
Axial pressure	T	10
Lifting force	T	60
Fast lifting speed	m/min	29
Fast feeding speed	m/min	51
Max rotary torque	Nm	24000/12000
Max rotary speed	r/min	75/150
Big auxiliary winch lifting force	T	4
Small auxiliary winch lifting force	T	1.5
Jacks stroke	m	1.7
Drilling efficiency	m/h	10-35
Moving speed	Km/h	6
Uphill angle	/	21°
Weight	T	23
Dimension	mm	700022503000
Working condition	/	Unconsolidated formation and stone head
Drilling method	/	Top drive hydraul ic rotary and pushing, hammer or mud drilling
Matched DTH hammer	/	Medium and high air pressure series
Optional accessories	/	Mud pump, Centrifugal pump, Generator, Foam pump

Company Profile

1.What can you buy from us?
DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.

2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
