High Efficiency Screw Air Compressor 15bar Mining Rotary Screw Air Compressor Machine
The mining-purpose portable rotary screw air compressor is a robust and mobile power source designed to deliver a continuous,
high-volume supply of compressed air in demanding underground and surface mining environments. Its core function is to provide
reliable energy for pneumatic tools, most notably Down-the-Hole (DTH) hammers on drill rigs, as well as for ventilation and other
auxiliary operations.
The heart of the unit is its rotary screw compression element. This system operates by trapping air between two intermeshing helical
screws (rotors). As the rotors turn, the volume of the air pockets is progressively reduced, efficiently compressing the air.
This mechanism is renowned for its durability, energy efficiency, and ability to provide a steady, pulsation-free airflow, which is critical
for the consistent performance of drilling equipment.
Products Description
| Model | XRQP555-15C |
| F.A.D m³/min/CFM | 15/550 |
| Pressure Bar/PSI | 15/220 |
| Fuel Tank Capacity(L) | 190 |
| Oil-gas Tank Capacity(L) | 30 |
| Outlet Valve | 1*G3/4'' 1*G1 1/2'' |
| Air End | single stage compression |
| Model Number | 6BTAA5.9-C205 |
| Rated Power(kw) | 153 |
| Rated Speed(rpm) | 2000/1400 |
| Dimension (mm) | 3000*1990*2200 |
| Shipping Dimension (mm) | 2750*1500*1900 |
| Weight(kg) | 1880 |
| Type | 2 wheels |
