Paper Carton Doctors Blade For Chain Printer Color Flexo Printing Machine

1.Summarize

The graphic drawings to be printed are first made into a printing plate, mounted on a printing machine, and then the ink is coated manually or by a printing machine on the plate where there are words and images, and then directly or indirectly transferred to the paper or other substrate, so as to reproduce the same printing plate.

2.Features and Characteristics

1.The machine composed with printer, slotter parts, can process 1-10mm cardboard printing creasing slotting etc. procedures.

2.Wall board material is casting iron, thickness 40mm, will not be out of shape. Spot facing work adopt high precision display processing, center distance of holes can reach ±0.01mm.

3.Helical tooth gears on main drive which adopted 45# steel, treated with gear shaving with high precision facility, closed spray lubrication system, put oil before run the machine, can lower down the noise, decrease the abrasion of gears, and prolong the lifetime of gears.

4.Adopt the planetary gears phase for the printer slotter driving structure, precise and durable. Phase adjustment adopt Taiwan motor and high quality sensor control, precision is ±0.1mm, exact and reliable.

5.All bearings use HRB brand.

6.Adopt electrical separation, pneumatic locking, pneumatic edition lifting, electric ink distribution, can realize the ink continuous supplying when stop the machine, avoid the ink drying and fading phenomenon when machine stop will affect the printing effect.

3.Technical Parameters
