1224 Corrugated Carton Box 4 Color Printer Slotter Die Cutter
4 Colors 1224 Flexo Printer Slotter Die Cutter Machine For Corrugated Carton Box
Whole machine character
1 . It adopts the computer to control the storage order with changing the lists quick and
convenient
2 . All of the transmission gears and rollers adopt good quality steel with heat treatment and
grinding.
3 . All of the units marches with alarm ringing , each unit sets a sudden stop switch to ensure
the safety of the operator.
4 . The balance device of the engine oil
5 . All drive rollers are high quality steel, hard chrome plated, surface grinding
6 . The wall plate is high quality steel, which is processed by CNC machining center after stress removal
7 . Paint spraying process: before painting, parts through the de-rusting - phosphating - spray - paint - baking paint, so that the paint rust, hard surface, paint more durable
8 . All of the units marches with alarm ringing , each unit sets a sudden stop switch to ensure
the safety of the operator.
9 . Machine with large screen display table, display the machine printing speed (by pcs/hour), convenient for operating personnel in different directions machine is easy to see the running speed of the machine.
10 . Lubricating oil automatic balancing device to keep all units of lubricating oil on the same horizontal line
11 . The computer control system can store up to 999 orders.
12 . Automatic zero function
Technical parameters:
| NO. | Parameter name | Unit | model |
| 1 | Design speed | Piece/min | 260 |
| 2 | The maximum size feeding paper | mm | 1200x2400 |
| 3 | The minimum size feeding paper | mm | 300x600 |
| 4 | The maximum size of feeding paper by partition | mm | 1500x2400 |
| 5 | The maximum size of printing area | mm | 1200x2360 |
| 6 | Printing precision | mm | ±0.5 |
| 7 | Standard plate thickness | mm | 7.2 |
| 8 | Printing paperboard thickness range | mm | 2-11 |
| 9 | Printing roller adjustment | degree | 360° |
| 10 | Printing roller lateral adjustment | mm | ±10 |
| 11 | Slotting precision | mm | ±1 |
| 12 | Minimum slotting distance(opposite direction) | mm | 230x65x230x65 |
| 13 | Maximum slotting depth | mm | 300 |
Part list:
| No | Name | Brand |
| 1 | Roller | HEBEI |
| 2 | Anilox roller | HAILI from Jiangsu |
| 3 | Bearing of cylinder and roller | NSK |
| 4 | Other bearing | Domestic |
| 5 | Elect parts | Schneider |
| 6 | PLC | Omron |
| 7 | Encoder | Automics Korea/SICK GERMAN |
| 8 | Touching screen | MCGS |
| 9 | Ink pump(single direction) | CHANGJINA From Wuhan |
| 10 | Die-cutter pad | MAXDURA Taiwan |
| 11 | converter | DELTA |
| 12 | Solenoid valve | AIRTAC |
| 13 | Air blower | Ouguan blower |
| 14 | Glue machine servo motor | LESHENGHE |
| 15 | Glue machine motor | TECO Qingdao |
| The air source provide by the customer | ||
