Brass 250V M2.5 JL127 PCB Terminal Connector 26AWG PA66 5.08mm Pitch
Brass 250V M2.5 JL127 PCB Terminal Connector 26AWG 5.00 5.08mm Pitch
Specifications:
| Rated Currency: | 300V,12A |
| Dieletric Strength: | AC2000V/1 Minute |
| Insularion Resistance: | 500mΩ Min |
| Contact Resistance: | 20mΩ Max |
| Screw Torque: | 0.4Nm(3.5Lb.in) |
| Wire Range: | 26-14AWG 2.5M㎡ |
| Strip Length: | 5-6mm |
| Term. Range: | -40℃~+105℃ |
| Max Solering | +250℃.5S |
| Housing Material: | PA66(UL94 V-O) |
| Contact: | Steel, Tin Plating |
| Clamp: | Brass/Steel, NI Plating |
| Wire Protector: | Brass,Ni Plating |
| Screw: | - |
Company history:
In July,2004, Shenzhen Jinling Electronic CO., Ltd was established, the company focused on connector metal stamping mold R&D , manufacturing and plastic mold and assembly.
In June,2005 the company has passed the CQC certifications ISO9001:2008 and ISO14001:2004.
In 2007, the company registered the trademarks”JILN”and”NETECH”
In January,2008, the produ rct of the company were rated as good quality products by Market Protection Committee of China’s Famous brand products.
In April,2008, The products of the company were rated as “Green Products” by international Green Management Committee.
Our business concept:integrity,gratitude and responsibility.
Our business strategy:quality first,customer first,excellence,team work!
Our service philosophy:speed,precise,considerate,carefully,elaborately,diligently.
Service purpose provided quick, decisive, accurate thoughtful service beyond what you think.Carefully, meticulously, attentively, picky customers is our mentor, regards complaining customer as friend.
Our value: committed to providing competitive solutions and diversified products of high quality to customer.
Enterprise positioning: to create brand improve enterprise awareness, to be a pioneer and leader in connector industry.
Team culture working happy to achieve the goal of team, to realized the dream of individuals.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
