Zipper Doypack Pouch Filling Machine For Juice Pouch Filling Sealing

EM-270S standy bag packing  machine is suitable for packing liquid and daily using goods etc. Different filling methods can be used for different products.

Feature:

Choices for mutilple sealing types of international standard.Safety protection by mutilple layers to keep products from penetration.

Visible during the packing ,easy to learn the operation, convenient and quick to adjust package size.

The main characteristics of equipment

It is suitable for filling packing different liquid, paste and cream products such as water, oil, milk, juice, ketchup, tomato
sauce, peanut butter, honey, mayonnaise, liquid detergent, shampoo, body washing and other non free-flowing liquid when equipped
with different filling machines like Piston Pump Filling, Peristaltic Pump Filling, Haibar Pump Filling. With the suitable filling
solution to meet the filling accuracy and packing speed requirements and avoid the liquid material bubble, forming, dripping, and
splashing. The horizontal pouch packaging machine is a fully-automatic packing machine, which is widely used for food / beverage
/cosmetics/chemicals/pharmaceuticals packaging. The packing material can be regular laminated film such as, PE / AL / PET PE / NY
/ AL / PET; CPP / NY / AL / PET.

Technical Parameter:

• Pouch Width 110mm-270mm
• Pouch Length 110mm-340mm
• Max Volume 800ml
• Speed 30-70 pouch/min.
• Pacing Accuracy <±1.5%
• Reel 600mm
• Electricity Consumption 5.5KW
• Air Consumption 0.6m³/min
• Weight 2200KG
• Size (L×W×H) 5500mm×960mm×1370mm
