Rail Whell Movable 1200mm Belt Conveyor Machine
Rail Whell Movable 1200mm Belt Conveyor Machine
Use and characteristics
The use effect of reversible bin distribution belt conveyor is the same as that of unloading trolley machine, which is under the belt conveyor
Belt conveyor consists of two or more pulleys, with a continuous loop of material - the conveyor belt - that rotates about them. One or both of the pulleys are powered, moving the belt and the material on the belt forward.With the global economic growth, belt conveyor technology has become one of the forefront of the development of modern science and technology. Today's global economy needs to design and produce "environmental protection" type conveyor, which can not pollute the surrounding environment. It can design long-distance, high belt speed, large capacity, high power according to the transportation needsThe components of the reversible bin distribution mobile belt conveyor are basically the same as the belt conveyor. The structure is as follows: conveyor belt, idler, frame, roller, cleaning device, etc. at present, the reversible bin distribution belt conveyor is developing towards the direction of long distance, high speed and low friction, among which the air cushion mobile conveyor appeared in recent years is one. In the design, manufacture and application of reversible bin distribution belt conveyor, at present, China is equivalent to the advanced level of foreign countries.
The reversible bin distribution belt conveyor is characterized by simple equipment and reliable operation. flexible,
2. Two way operation realizes two-way unloading.
3. The height of the whole machine is reduced, which is suitable for the occasion where the unloading truck cannot be used.
4. The occupied space is small, which reduces the cost of civil engineering
-
Material to be processed: _____
-
Handling capacity:_____
-
Bulk Density: _____t/m3
-
Material temperature: _____℃
-
Water content:____%
-
Material is corrosive or not: ____
-
Material is sticky or not: ____
-
Working environment temperature: ______ ℃
-
Working voltage:____V_____hz_____phase
| Bmm | Dmm | Hmm | Smm | Amm | Emm | Cmm | Pmm | Rmm | emm |
| 500 | 500 | 900 | 900 | 700 | 776 | 1300 | 1565 | 1700 | 1400 |
| 650 | 1060 | 850 | 926 | ||||||
| 800 | 1000 | 1440 | 1140 | 1126 | 1565 | ||||
| 1000 | 630 | 1640 | 1360 | 1360 | 1400 | 1718 | 1400 | ||
| 1200 | 1100 | 1850 | 1600 | 1610 | 1520 | 1800 | 1970 | ||
| 1400 | 800 | 1150 | 2050 | 1800 | 1810 | 1400 | 1697 | 2200 | 1520 |
