Concrete Batching U Shape Auger Screw Feeder Conveyor
Concrete Batching U Shape Auger Feeder Conveyor
Characteristics of Screw Feeder Conveyor
Screw Feeder Conveyor advantage are : It can realize sealed transportation, which is conducive to the transportation of easy-to-fly, hot and strong-smelling materials, which can reduce environmental pollution and improve the working conditions of port workers.
Easy to load and unload. The horizontal screw conveyor can be loaded and unloaded at any point on the conveying line; the vertical screw conveyor can be equipped with a relatively screw-type reclaiming device to have excellent reclaiming performance.
Application scope of Screw Feeder Conveyor
Screw Feeder Conveyor is widely used in building materials, metallurgy, chemical industry, machinery, light industry, grain and food industry. U-type screw conveyor is suitable for conveying powder Shaped, granular, small bulk materials, such as cement, fly ash, grain, chemical fertilizer, mineral powder, sand, soda and so on. U-shaped screw conveyor is not suitable for transporting materials that are easy to deteriorate, sticky and easy to caking. The working environment temperature of the conveyor is usually-20 °40 °, the temperature of the conveying material is generally 20 °80 °℃, the U-shaped screw conveyor is suitable for horizontal and small inclination arrangement, and the inclination angle is not more than 15 degrees. If the tilt angle is too large, the tubular screw conveyor should be selected.
Technical parameter of Screw Feeder Conveyor
| Model |
Diameter mm |
Pitch mm |
Speed r/min |
Standard Capacity(m3/h) |
Speed r/min |
Standard Capacity(m3/h) |
Speed r/min |
Standard Capacity(m3/h) |
||||||
| φ0.45 | φ0.33 | φ0.15 | φ0.45 | φ0.33 | φ0.15 | φ0.45 | φ0.33 | φ0.15 | ||||||
| LS20 | 200 | 200 | 100 | 16.9 | 12.4 | 5.6 | 80 | 13.5 | 9.9 | 4.5 | 63 | 10.7 | 7.8 | 3.6 |
| LS315 | 315 | 315 | 80 | 52.9 | 38.8 | 17.6 | 63 | 41.6 | 30.5 | 13.9 | 50 | 33.1 | 24.2 | 11 |
| LS400 | 400 | 355 | 71 | 85.3 | 62.5 | 28.4 | 56 | 67.3 | 49.3 | 22.4 | 45 | 54.1 | 39.6 | 18 |
| LS500 | 500 | 400 | 63 | 133.2 | 97.7 | 44.4 | 50 | 105.8 | 77.6 | 35.3 | 40 | 84.6 | 62.0 | 28.2 |
Selection Conditions of Screw Feeder Conveyor
| Material to be processed: _____ | Working environment is indoor or outdoor:________ |
| Handling capacity: ________per hour | Working environment temperature: _______ ℃ |
| Bulk Density: _____t/m3 | Installation form is horizontal or inclined : ________ |
| Conveying distance: ________ | If it is inclined,what is the inclined degree_____° |
| Material size:____mm | Water content:____% |
| Material temperature: _______ ℃ | Working power supply: _____V ______HZ ______PH |
