Double Outlets Horizontal Screw Loader Conveyor Easy To Use
Price:
Negotiable
MOQ:
1 piece
Delivery Time:
10 work days
Brand:
Jinrui/Kunwei
Product Description
Double outlets Easy To Use Horizontal LS Screw Loader Conveyor
Summray of Screw Loader Conveyor
Compared with the GS type screw conveyor, the head and tail bearings of the LS type screw conveyor are moved to the outside of the shell, the hanging bearing adopts the rolling structure, the pulley bearing is exchanged, and the dust-proof sealing device is installed. Good performance, strong wear resistance, low resistance and long life. Sliding bearing bushes include cast copper tiles that need to be lubricated, alloyed and ground cast iron tiles and copper-based graphite oil-less lubricating tiles. The discharge end is equipped with a cleaning device. The whole machine has low noise, strong adaptability, convenient operation and maintenance, and inlet and outlet ports. The location arrangement is flexible.
Characteristics of Screw Loader Conveyor
1, convenient maintenance;
2, simple structure;
3,small size of the cross section;
4,can enter and leave materials at any position in the length direction;
5, can use the cover of the tight closed housing to achieve a better sealing effect;
Therefore, screw conveyor is widely used in various industrial sectors to transport a variety of powdered, granular and small materials, such as cement, coal ash, coal, sand, cereals and so on; it is not easy to transport viscous caking materials which are easy to deteriorate.
Therefore, screw conveyor is widely used in various industrial sectors to transport a variety of powdered, granular and small materials, such as cement, coal ash, coal, sand, cereals and so on; it is not easy to transport viscous caking materials which are easy to deteriorate.
Technical parameter of Screw Loader Conveyor
|
Model
|
Diameter
mm
|
Pitch
mm
|
Speed
r/min
|
Standard
Capacity(m3/h)
|
Speed
r/min
|
Standard
Capacity(m3/h)
|
Speed
r/min
|
Standard
Capacity(m3/h)
|
||||||
|
φ0.45
|
φ0.33
|
φ0.15
|
φ0.45
|
φ0.33
|
φ0.15
|
φ0.45
|
φ0.33
|
φ0.15
|
||||||
|
LS200
|
200
|
200
|
100
|
16.9
|
12.4
|
5.6
|
80
|
13.5
|
9.9
|
4.5
|
63
|
10.7
|
7.8
|
3.6
|
|
LS315
|
315
|
315
|
80
|
52.9
|
38.8
|
17.6
|
63
|
41.6
|
30.5
|
13.9
|
50
|
33.1
|
24.2
|
11
|
|
LS400
|
400
|
355
|
71
|
85.3
|
62.5
|
28.4
|
56
|
67.3
|
49.3
|
22.4
|
45
|
54.1
|
39.6
|
18
|
|
LS500
|
500
|
400
|
63
|
133.2
|
97.7
|
44.4
|
50
|
105.8
|
77.6
|
35.3
|
40
|
84.6
|
62.0
|
28.2
|
|
LS630
|
630
|
450
|
50
|
188.9
|
138.5
|
63.0
|
40
|
151.1
|
110.8
|
50.4
|
32
|
120.9
|
88.6
|
40.3
|
1.Q:How can i choose a suitable model for ourself?
A:pls supply the below information.
1.Transport material and its particle size
2.horizontal transport and inclined transport?If inclined transport,pls let me know the inclined angle.
3.transport distance
4.capacity per hour
2.Q:How is the MOQ.
A:one set can be accepted.
