0.4kW - 22kW Mobile Industrial Belt Conveyor Equipment For Bags
DY Type Mobile Belt Conveyor Portable Belt Conveyor For Bags And Bulk Materials
Product Description
DY type mobile belt conveyor is one of the most commonly used conveying equipment.It is especially suitable for conveying scattered materials and irregular goods. With a constant speed operating system or adjustable speed operating system, not only bulk materials are transported, but also packaging materials and bags. In addition, the machine can convey food, medication, chemical by adopting special belt for these industries.
Mobile belt conveyor is consist of main body of metal frame, pulleys, rollers, belt, motor, reducer and control panel, etc. The materials of conveyor belt are usually rubber, plastics, PVC, PU and other materials. The frame materials can be carbon steel, stainless steel, or aluminum. The driving mode is gear motor or electric roller. Belt is looped around the head pulley, tail pulley and rollers.When the pulley is driven by a motor, the pulley slides between the idlers and moves the product to the top of the pulley. The machine is light, for reducing the labor intensity of the workers and improving the work efficiency.
Main Features
1. Simple structure and easy installation.
2. Low rate of breakdown and adapt to different using condition.
3. Various design form can meet different industries.
4. Cheap cost and long working life.
5. Easy to move by special wheels.
Main Parameters
| Item | DY400 | DY500 | DY650 | DY800 | DY1000 | |
| Length of machine(m) | 3~20 | |||||
| Belt width(m) | 400 | 500 | 650 | 800 | 1000 | |
| Belt speed(m) | 0.4~1.25 | |||||
| Conveying height | 6.52 | |||||
| Conveying capacity | (m3/h) | 60 | 120 | 220 | 500 | 1000 |
| (t/h) | 40 | 80 | 150 | 200 | 300 | |
| dip angle(°) | 0°~18° | |||||
| Electric roller | Model | DY | DY | DY | DY | DY |
| Power(kw) | 2.2 | 2.2 | 3.0 | 4.0 | 7.5 | |
Main Advantages
Packing & Shipping
Well-designed packing and transportation ensure that the products can be delivered intactly to our customers.
Field Usage
