High Efficiency Steel Bucket Elevator , Grain Bucket Elevator CE Approval
High-Efficiency Steel Belt Bucket Elevator Grain Rice Bucket Elevator
Product Description
TDG series bucket elevator is a new-generation product developed by our company through the combination of learning from new foreign technology and domestic production and using practice. It is suitable for the vertical hoisting of dry, bulk, powdery materials or materials of small granule. It is widely used in the hoisting system of bulk materials in building materials, metallurgy, chemical industry, food, electric power and other industries.
In terms of kiln feeding into kiln tail, raw material into the homogenization silo, and cement putting in storage in the new dry process cement plant, it is an ideal piece of alternative equipment for foreign products of the same specification.
Main Advantages
1. Large throughput, high lift height.
2. The temperature of transported material can reach 120℃.
3. Long service life, good operational reliability, and the failure-free time can exceed 30,000 hours.
4. The belt with steel wire rope core, has good toughness, high strength.
5. The operation and maintenance are convenient, and there are little vulnerable parts, and the maintenance costs are more than 80% less than that for the common bucket elevator.
6. The equipment adopts the heavy hammer tensioning device, which has constant tensioning force and can help avoid the belt slipping, thus ensuring the normal operation of the equipment.
Main Parameters
| TDG200 | |||
| Bucket type | Sh | Zh | |
| Conveying capacity, m³/h | 45 | 31 | |
| Bucket | Volume, L | 4.1 | 2.9 |
| Distance, mm | 300 | ||
| Total weight of belt and bucket per meter length, kg/m | 21.5 | ||
| Bucket speed, m/s | 1.2 | ||
| Max. hoisting height, m | 80 | ||
Sh: Deep bucket: Used for conveying dry, loose, easily thrown powder or small pieces of materials, such as cement, coal, gravel, grain, etc.
Zh: Medium-deep bucket: Used for conveying wet and viscous materials, such as sugar, wet fine sand, crushed coal, fertilizer, etc.
