Professional Z Type Belt Conveyor , Mining Belt Conveyor With Sidewall


High quality Z Type Belt Conveyor Inclined Belt Conveyor With Sidewall

Product Description

High inclination angle belt conveyor (also called large dip corrugated belt conveyor) with a large inclination (90 degrees vertical) transport. So that it is ideal equipment for achieving large angle conveying. Widely adopted in underground mining projects, open pit mining, large dump trucks, metallurgy, electricity, coal, foundries, construction, food, cement works, fertilizer, etc. According to the type of belt, it can be divided into ordinary belt conveyor and PVC belt conveyor.
Main Parameters


Main Features

1.Belt Conveyors can work at the ambient temperature between - 10 ℃ and 40 ℃.

2.Choose conveyor belt reasonably according to different temperature of material.The temperature is generally no higher than 60℃.

3.Heat-resisting type belt must be used when conveying materials with higher temperature


Advantages

1. The maximum conveying angle can reach up to 90°, which can save the floor area, equipment investment and civil engineering costs, and achieve good comprehensive economic benefits
2. Simple structure, the main components can be used with the general belt conveyor, making it convenient for use and maintenance.
3. Smooth operation, low noise.
4. Low energy consumption.
5. The horizontal conveyor section of the head and tail can be set to any length to facilitate connection with other equipments.
Details Show


Field Usage
