Industrial Electric Vibrating Screen Machine , Flour Sifter Machine 1~5 Layers
Rotary Vibrating Screen Electric Vibrating Industrial Flour Sieving Sifter
Product Description
XZS series rotary vibrating screen is a high-precision fine powder screening machine. It has low noise and high efficiency. It takes 3-5 minutes to change the screen quickly. It has a fully enclosed structure and is suitable for screening and filtering materials such as granules, powder and slime. The rotary vibrating screen is a vertical motor as the excitation source. The eccentric weights are installed on the upper and lower ends of the motor to convert the rotary motion of the motor into three-dimensional motion of horizontal, vertical and tilt, and then transmit this motion to the screen surface. . Adjusting the phase angle of the upper and lower ends can change the movement trajectory of the material on the screen surface.
Main Parameters
| Model | Power(kw) | Valid Diameter of screen(mm) | Volume(mm) | Layers |
|
XZS-400-1S XZS-400-2S XZS-400-3S |
0.18kw |
320mm |
580*580*560 580*580*660 580*580*760 |
1 2 3 |
|
XZS-600-1S XZS-600-2S XZS-600-3S |
0.55kw |
550mm |
800*800*680 800*800*780 800*800*880 |
1 2 3 |
|
XZS-800-1S XZS-800-2S XZS-800-3S |
0.75 kw |
750mm |
900*900*780 900*900*930 900*900*1080 |
1 2 3 |
|
XZS-1000-1S XZS-1000-2S XZS-1000-3S |
1.5 kw |
950mm |
1160*1160*880 1160*1160*1030 1160*1160*1180 |
1 2 3 |
|
XZS-1200-1S XZS-1200-2S XZS-1200-3S |
1.75 kw |
1150 mm |
1360*1360*980 1360*1360*1160 1360*1360*1360 |
1 2 3 |
|
XZS-1500-1S XZS-1500-2S XZS-1500-3S |
2.2 kw |
1450mm |
1850*1850*1130 1850*1850*1330 1850*1850*1550 |
1 2 3 |
|
XZS-1800-1S XZS-1800-2S XZS-1800-3S |
2.2 kw |
1750mm |
2200*2200*1360 2200*2200*1460 2200*2200*1680 |
1 2 3 |
Application
Industry: Resin powder, pigment, washing powder, micro powder, paint, soda ash, lemon powder, rubber, plastic, etc.
Abrasives, ceramics industry: alumina, quartz sand, mud, spray soil particles.
Food industry: sugar, salt, alkali, MSG, milk powder, soy milk, yeast, fruit juice, soy sauce, vinegar, etc.
Papermaking industry: coating paint, clay mud, black and white liquid, waste liquid, papermaking liquid, waste water recovery.
Metallurgical industry: titanium oxide, zinc oxide, electromagnetic materials, metal powder, electrode powder, etc.
Pharmaceutical industry: Chinese medicine powder, Chinese medicine liquid, Western medicine powder, Western medicine liquid, Chinese and Western medicine granules, etc.
Environmental protection: garbage, human and animal waste, waste oil, food waste water, waste water processing, etc.
Products Show
Packing and Shipping
Well-designed packing and transportation ensure that the products can be delivered intact to our customers.
Customer Case
