Stainless Steel Movable Feed Screw Conveyor High Temperature Resistance
Stainless Steel Movable Feed Screw Conveyor High Temperature Resistance
Product Description
Screw conveyor is a kind of continuous transmission equipment which without immunity traction components, it uses rotation screw to convey material. The screw conveyor is of simple structure, low marking cost, strong sealing, safe ,convenient operation and other advantages, It allows multiple inlets and outlets. It is widely used in various industrial department(such as building materials, chemicals, electric power, metallurgy, coal, mine, food and other industries)to convey powder, granular and lump material, such as, coal, ash, slag, cement, food, etc. The temperature of material is less than 200°C. Screw conveyor is not suitable for transporting those material which is perishable, with big viscous and easy caking. In the concrete mixing plant screw conveyor's effect reflected to the fullest.
Main Features
1. Compact structure, small cross section, light weight.
2. Flexible technological arrangement, easy to be installed, dismantled and moved, and safe operation.
3. It has the characteristics of high temperature resistance and corrosion resistance, and has a longer service life under the premise of ensuring food safety.
4. Conveyor has big transport capacity, long distance available.
5. Stable and controllable start, continuous and highly efficient operation.
Main Parameters
| Main technical parameters | |||||||||||
| Specifications and models | LS100 | LS160 | LS200 | LS250 | LS315 | LS400 | LS500 | LS630 | LS800 | LS1000 | LS1250 |
| Screw diameter(mm) | 100 | 160 | 200 | 250 | 315 | 400 | 500 | 630 | 800 | 1000 | 1250 |
| Pitch(mm) | 100 | 160 | 200 | 250 | 315 | 355 | 400 | 450 | 500 | 560 | 630 |
| Speed of revolution (rpm) | 140 | 112 | 100 | 90 | 80 | 71 | 63 | 50 | 40 | 32 | 25 |
| Conveying capacity (m3/h) | 2.2 | 7 | 13 | 22 | 39 | 62 | 92 | 145 | 200 | 300 | 380 |
Packing & Shipping
Well-designed packing and transportation ensure that the products can be delivered intactly to our customers.
