Vertical Bucket Elevator Conveyor Coal Cement
Vertical Bucket Elevator Conveyor Coal Cement
Bucket elevator has large throughput, great enhancing-height, stable and reliable operation, long life and other significant advantages. Hybrid-type or gravity discharge, earth-type loading. Application to transport packing density of less than 1.5t/m³, easy to take out the powder, granular, small block of low-mill cut materials, such as coal, cement ,gravel ,sand fertilizer, food and so on. Delivery temperature of the material does not exceed 250°C.
Bucket Conveying Elevator Technical Parameter:
| Model |
Capacity m 3 /h |
Max. size of material (mm) | ||||
| Percentage % | ||||||
| 10 | 25 | 50 | 75 | 100 | ||
| NE15 | 15 | 65 | 50 | 40 | 30 | 25 |
| NE30 | 32 | 60 | 75 | 58 | 47 | 40 |
| NE50 | 60 | 90 | 75 | 58 | 47 | 40 |
| NE100 | 110 | 130 | 105 | 80 | 65 | 55 |
| NE150 | 170 | 130 | 105 | 80 | 65 | 55 |
| NE200 | 210 | 170 | 135 | 100 | 85 | 70 |
| NE300 | 320 | 170 | 135 | 100 | 85 | 70 |
| NE400 | 380 | 205 | 165 | 125 | 105 | 90 |
| NE500 | 470 | 240 | 190 | 145 | 120 | 100 |
| NE600 | 600 | 240 | 190 | 145 | 120 | 100 |
| NE800 | 800 | 275 | 220 | 165 | 135 |
110 |
Features of Bucket Conveying Elevator:
1. Bucket Elevator has characteristics of large transport capacity, high elevation, stable operation and long working life.
2. The machine is applicable for conveying the powder, grain and small block materials, such as coal, cement, block, sand, clay and ore.
3. Bucket Elevator is allowed to convey materials with high temperature(250°c) when armed with special chain structure, and the elevating height can reach 40m.
