Corrugated Sidewall Grain Storage Industrial Belt Conveyor
Professional Corrugated Sidewall Belt Conveyor Manufacture in China
Product Description
Corrugated Sidewall Belt Conveyor (also called large dip corrugated belt conveyor) with a large inclination (90 degrees vertical) transport. So that it is ideal equipment for achieving large angle conveying. Widely adopted in underground mining projects, open pit mining, large dump trucks and food industry etc.
Advantages
1. Low maintenance cost.
2. Large transport capacity, and it can avoid material spilling effetely.
3. The belt can facilitate switching from horizontal to inclined conveying and from inclined to horizontal conveying.
4. It saves a lot space as it allows material conveying at 0-90 degree.
Main Parameters
| Roller form |
Transmission speed(m/s) |
Belt width(mm) | |||||
| 500 | 650 | 800 | 1000 | 1200 | 1400 | ||
| Capacity(m3/h) | |||||||
| Trough idler | 0.8 | 78 | 130 | -- | -- | -- | -- |
| 1.0 | 97 | 164 | 278 | 435 | 655 | 891 | |
| 1.25 | 122 | 206 | 348 | 544 | 821 | 1115 | |
| 1.6 | 156 | 264 | 445 | 696 | 1048 | 1427 | |
| 2.0 | 191 | 323 | 546 | 853 | 1284 | 1748 | |
| 2.5 | 232 | 391 | 664 | 1033 | 1556 | 2118 | |
| 3.15 | -- | -- | 824 | 1233 | 1858 | 2528 | |
| 4.0 | -- | -- | -- | -- | 2202 | 2996 | |
| Flat idler | 0.8 | 41 | 67 | 118 | -- | -- | -- |
| 1.0 | 52 | 88 | 147 | 230 | 345 | 469 | |
| 1.25 | 66 | 110 | 184 | 288 | 432 | 588 | |
| 1.6 | 84 | 142 | 236 | 368 | 558 | 753 | |
| 2.0 | 103 | 174 | 289 | 451 | 677 | 922 | |
| 2.5 | 125 | 211 | 350 | 546 | 821 | 1117 | |
Remark: The conveying capacity in the form is based on the belt speed 1m/s, and it will vary according to the belt speed.
Working Principle
Professional Corrugated Sidewall Belt Conveyor Manufacture In China
Corrugated Sidewall Belt Conveyor is composed by two endpoint pulleys and a closed conveyor belt. The pulley that drives conveyor belt rotating is called drive pulley or transmission drum; the other one–only used to change conveyor belt movement direction–is called bend pulley. Drive pulley is driven by the motor through reducer, and conveyor belt dragging relies on the friction drag between the drive pulley and the conveyor belt. The drive pulleys are generally installed at the discharge end in order to increase traction and be easy to drag. Material is fed on the feed-side and landed on the rotating conveyor belt, then rely on the conveyor belt friction to be delivered to discharge end.
Application
Corrugated Sidewall Belt Conveyor widely used in mining,gravel field, metallurgy, building materials,chemical industry,mineral processing,coal mining and other industries.It can convey bulk material like coal,cement,sand,cereal etc.And can convey lump material,such as rock.
We can choose the most suitable the machine according to customer requirements.
1. What is the conveying material and its physical characteristics? such as bulk density, feeding size, temperature, mositure content etc.
2. What is the processing capacity of the elevator?
3. What is the lifting height of the elevator (distance between inlet and outlet)?
