Product Description
Shaftless Screw Conveyor is the ideal solution for hard-to-transport materials ranging from irregularly shaped dry solids such as scrap wood and metals, to semiliquid and sticky materials including pulp, compost,food-processing waste, hospital waste, and wastewater products.
Shaftless Screw Conveyor consists of rotating shaftless screw inside U-shaped trough having an inlet hopper and outlet spout,being the rest of conveyor completely closed. The feed is pushed into the feed inlet and then moves to the outletspout under thepushing of the screw.
Main Parameters of Screw Conveyor
| Model | LS114 | LS133 | LS159 | LS219 | LS245 | LS273 | LS315 | LS400 | LS500 | LS600 |
Diameter (mm) | 114 | 133 | 159 | 219 | 245 | 273 | 315 | 400 | 500 | 600 |
Rated speed (r/min) | 84- 130 | 84-130 | 84-130 | 84-130 | 84-130 | 84-130 | 84-130 | 62- 100 | 62- 100 | 62- 100 |
Reference capacity (m³/h) | 1 | 1.3 | 5 | 15 | 20 | 30 | 40 | 45 | 70 | 100 |
| Motor power(Kw) | 2.2-18.5 | |||||||||
| Admission biggest gradient(o) | <60 | |||||||||
Application of Shaftless Screw Conveyor
Shaftless Screw Conveyors are the ideal solution for hard-to-transport materials ranging from irregularly shaped dry solids such as scrap wood and metals, to semiliquid and sticky materials including pulp, compost, food-processing waste, hospital waste, and wastewater products.
Customer Case of Shaftless Screw Conveyor
