Product Description
U Shaped Screw Auger Conveyor Machine are spiral bulk material transportation systems that convey raw ingredients to and from processing areas that are on different levels of a facility. These conveyors can horizontal transport materials, also it can slanted at different angles to economically elevate and convey materials up and down floors. They require ample space and an increased amount of power to lift the material, depending on the steepness of the angle.
Main Features of U Shaped Screw Auger Conveyor
| 1.Fully automatic electric protection can be co-controlled with sludge dewatering system. |
| 2. The flight is made of stainless steel which is strong enough and anti-corrosive. |
| 3.Closed running makes the noise low and surroundings better. |
| 4.Using wear-resisting material in the inner layer of trough, its examining and repairing is convenient. |
| 5.Its length, angle and discharging hopper can be manufactured according to customer's requirements. |
| 6.Compact structure, convenient installation with expansion bolts. |
Main Parameters of U Shaped Screw Auger Conveyor
| Model | Item | |||||||
|
Screw diameter (mm) |
Conveying distance(mm) |
Screw speed (r/min) |
largest feed ability (m³/h) |
Motor power (kw) |
Supporting reducer |
Material max size (mm) |
Reference weight (t) |
|
| SID1215 | 120 | 1500 | 20-80 | 1.4 | 1.1 | ZQ250 | 20 | 0.65 |
| SID1225 | 2500 | 0.87 | ||||||
| SID1615 | 160 | 1500 | 15-75 | 4.8 | 1.5 | ZQ250 | 25 | 0.78 |
| SID1625 | 2500 | 1.03 | ||||||
| SID2015 | 200 | 1500 | 15-60 | 7.4 | 2.2 | ZQ250 | 30 | 0.92 |
| SID2025 | 2500 | 1.23 | ||||||
| SID3015 | 300 | 1500 | 10-45 | 21.2 | 3 | ZQ250 | 40 | 1.10 |
| SID3025 | 2500 | 1.38 | ||||||
Packing & Shipping
Well-designed packing and transportation ensure that the products can be delivered intactly to our customers.
