Heat Resistant Sand Auger Conveyor System Ash Screw Conveyor
Screw Conveyor Sand Auger Conveyor System Ash Screw Conveyor
Product Description
Screw conveyor system is a machine that uses a motor to drive a screw to rotate and move materials to achieve the purpose of transportation. It can be transported horizontally, inclinedly or vertically, and has the advantages of simple structure, small cross-sectional area, good sealing, easy operation, easy maintenance, and convenient closed transportation. Screw conveyors are divided into shaft screw conveyors and shaftless screw conveyors in the form of conveyance, and are divided into U-shaped screw conveyors and tubular screw conveyors in appearance.
Application of screw conveyor system
It is widely used in mining ,metallurgy ,coal and other industries .The screw conveyor is suitable to convey powder, granule, patch and scattered material such as cement, dust coal, food, fertilizer, inder, sand,the temperature must be less than 200 °C. Material which is easily deteriorated,viscous and easily lump is unsuitable .
Main Parameters
| Main technical parameters | |||||||||||
| Specifications and models | LS100 | LS160 | LS200 | LS250 | LS315 | LS400 | LS500 | LS630 | LS800 | LS1000 | LS1250 |
| Screw diameter(mm) | 100 | 160 | 200 | 250 | 315 | 400 | 500 | 630 | 800 | 1000 | 1250 |
| Pitch(mm) | 100 | 160 | 200 | 250 | 315 | 355 | 400 | 450 | 500 | 560 | 630 |
| Speed of revolution (rpm) | 140 | 112 | 100 | 90 | 80 | 71 | 63 | 50 | 40 | 32 | 25 |
| Conveying capacity (m3/h) | 2.2 | 7 | 13 | 22 | 39 | 62 | 92 | 145 | 200 | 300 | 380 |
Packing & Shipping
Well-designed packing and transportation ensure that the products can be delivered intactly to our customers.
