Variable Speed Spiral Auger Conveyor Machine For Powder
Variable Speed Vertical Spiral Auger Conveyor Machine For Powder
Product Description
Spiral auger conveyors, also known as auger conveyor, are made for simple conveying duties applications.The real strength of our company,however,is our ability to produce individually designed units that include features to overcome awkward installations,materials that are difficult to handle,or include performance or process functions beyond simple conveying.Some requirements may be concerned with aspects of hygiene,others with bulk solids that have poor or delicate conveying properties.
Spiral auger conveyor is divided in two types rigid screw conveyor and shaftless screw conveyor.
Spiral auger conveyor is suitable for non-sticky powder and small particle material such as cement,fly ash,lime,flour,starch,food additive etc.
Main Parameters
| Model | WLS150 | WLS200 | WLS250 | WLS300 | WLS400 | WLS500 | ||
| Screw diameter(mm) | 150 | 184 | 237 | 284 | 365 | 470 | ||
| Thickness of screw blade | 14/20mm | 14/20mm | 16/20mm | 18/20mm | 18/20mm | 18/20mm | ||
| Thickness of liner board | 8-10mm | 10mm | 10mm | 10mm | 10mm | 10mm | ||
| Diameter of shell | 180 | 219 | 273 | 351 | 402 | 500 | ||
| Operating angle(α) | 0-45° | ≤30° | ≤30° | ≤30° | ≤30° | ≤30° | ||
| Max delivery length(m) | 12 | 13 | 16 | 18 | 22 | 25 | ||
| Capacity(t/h) | 2.4 | 7 | 9 | 13 | 18 | 28 | ||
|
|
Model | L≤7 | Y90L-4 | Y100L1-4 | Y100L2-4 | Y132S-4 | Y160M-4 | Y160M-4 |
| Power | 1.5 | 2.2 | 3 | 5.5 | 11 | 11 | ||
| Model | L>7 | Y100L1-4 | Y100L2-4 | Y112M-4 | Y132M-4 | Y160L-4 | Y160L-4 | |
| Power | 2.2 | 3 | 4 | 7.5 | 15 | 15 | ||
Application
The spiral auger conveyor has no central axis, so it is suitable for continuous conveying of materials with thick, easy winding, easy caking and poor fluidity, such as: sludge, wet sand, wood chips.
