Digital Feeder Belt Conveyor Weighing Scales Belt Feeder
Digital Conveyor Weigh Weighing Scales Belt Feeder
Product Description
Digital Conveyor Weighing Scale with high precision weighing, easy operation, fully automatic and so on, it is not only can be control by itself, but also can be connected by remote control.
Digital Conveyor Weighing Scale is equipping with frequency conversion motor and frequency regulator, the speed of belt will be adjusted automaticallyaccording to the actual capacity that you set up. It adopts dynamic constant weighing methods, frequency conversion control, belt automatic tension device, anti-deviation device, and site controlling switch.
Main Parameters
| Model No. | Belt width (mm) |
Length (m) |
Accuracy (%) |
Capacity (t/h) |
Allowed angle |
Sensor (unit) |
| 05 | 500 | 1.5-4 | ±0.5 | 15 | ≤6° | 2-4 |
| 06 | 650 | 1.5-4 | ±0.5 | 30 | ≤6° | 2-4 |
| 08 | 800 | 1.5-4 | ±0.5 | 80 | ≤6°° | 2-4 |
| 10 | 1000 | 1.5-4 | ±0.5 | 150 | ≤6° | 2-4 |
| 12 | 1200 | 1.5-4 | ±0.5 | 220 | ≤6° | 2-4 |
| 14 | 1400 | 1.5-4 | ±0.5 | 300 | ≤6° | 2-4 |
| 16 | 1600 | 1.5-4 | ±0.5 | 500 | ≤6° | 2-4 |
| 18 | 1800 | 1.5-4 | ±0.5 | 800 | ≤6° | 2-4 |
| 20 | 2000 | 1.5-4 | ±0.5 | 1000 | ≤6° | 2-4 |
Application
Digital Conveyor Weighing Scale is used for food, medical, chemical and mining and cement plant etc.
