Annealed Zr702 Zr704 Zirconium Foil Zr Foil Corrosion Resistance
Price:
100USD-200USd
MOQ:
10kgs
Delivery Time:
10-30days
Brand:
jx Zirconium Foil (Zr Foil)
Product Description
Zirconium Foil (Zr Foil)
Zirconium Foil (Zr Foil) is a hard, lustrous, silvery coloured metal which is extracted from its ores (the oxide or zircon, ZrSiO4) by conversion to the tetrahalide followed by reduction with magnesium. The metal is extremely corrosion resistant due to the formation of a stable oxide film and is unaffected by acids (with the exception of HF) and alkalis.
As a result of its corrosion resistance, zirconium is widely used in the chemical industry where corrosive agents are used. Also, due to its excellent high temperature properties, coupled with its low neutron absorption, it is used in the construction of nuclear reactors. The pure metal is also used as a lining in jet engines. Zirconium is used as an alloying element, the resultant alloys having improved mechanical properties.
The chemical properties of zirconium are very similar to those of hafnium. As a result, the normal chemical processes used for the extraction of zirconium will not remove hafnium, which can be present in commercial grades of zirconium at levels as high as 4.5%. A high purity grade of zirconium containing less than 0.01% hafnium is used for nuclear applications.
Specifications Of Zirconium Foil (Zr Foil)
Material
|
||
| Thickness | 0.5~50mm, or 0.02"~2" | |
| Width | <1000mm> | |
| Length | <2000mm> |
Composition of our Zirconium materials
| Zr 702 | Zr 704 | Zr 705 | Zircaloy-2 | Zircaloy-4 | |
| Sn | / | 1~2% | 1~2% | 1.2~1.7% | 1.2~1.7% |
| Fe | <0> | 0.1~0.2% | <0> | 0.07~0.2% | 0.07~0.2% |
| Cr | <0> | 0.1~0.2% | <0> | 0.05~0.15% | 0.05~0.15% |
| Ni | / | / | / | 0.03~0.08% | <0> |
| Hf | 1~2.5% | <4> | <4> | ||
| Nb | / | / | 2~3% | ||
| Zn+Hf | ~99.5% | ~97.5% | ~95.5% | ~98% | ~98% |
Physical Properties Zirconium Foil (Zr Foil)
| Material | State | Rm(≥)/MPa | Rp0.2(Pa | A50mm(≥)/% |
|
Zirconium 702 (UNS R60702) |
annealed | 379 | 207 | 16 |
|
Zirconium 704 (UNS R60704) |
annealed | 413 | 241 | 14 |
|
Zirconium 705 (UNS R60705) |
annealed | 552 | 379 | 16 |
Zirconium Foil (Zr Foil) Picture:
Zirconium oxide, zirconia (ZrO2), is used as an opacifier in vitreous enamels as well as a pigment. However, the main applications of zirconia make use of its excellent strength and high temperature properties, and it is used to manufacture foundry crucibles, bricks, ceramics and abrasives. It has sufficient strength to enable it to be used to fabricate high precision knife blades.
