OEM Welded Tie-rod Agricultural Tractor machinery Hydraulic Cylinder
JSRUIYA strives to accommodate OEMs across a broad range of industries. Our hydraulic cylinders are found in systems ranging from hoists to compacting equipment to dump trucks, servicing a broad range of applications throughout manufacturing, construction, waste management, food and beverage, and other industries. Our repair team supports a similarly broad set of industry clients. If it contains a hydraulic cylinder, we can usually fix or rebuild it.
Customized Double Acting Steel Hydraulic Cylinder for Agriculture Tractor Machine
Tie rod cylinder for agricultural machinery hydraulic cylinder Supplier
| HS Code | 8412210000 |
| Seal | Hallite,SKF,NOK,Guarnitec,Parker |
| Coating | chrome plated |
| Temperature | -30ºC~100ºC |
| Working pressure | 16Mpa,18Mpa |
| Stroke | 100mm-6000mm |
| Mounting Type | Earring-trunnion, double trunnion, double earring (eye end) |
| Warranty | One year after shipping arrival |
| Payment terms | T/T, L/C, West Union,Paypal |
| Delivery time | 20- 25 days after down payment |
| U-cup design |
| Lower running friction for smooth, fast operation |
| Lower friction means lower break-away pressure |
| No mis-staging |
| No seal adjustments required |
| No compression set like standard V-packing |
| Dry operation means no oil build up on stages |
| Longer seal life than V-packing |
| Better temperature range |
| Dual bearings provide more bearing surface area for greater support |
| Alloy tubing material |
| DIN ST 52.3 vs. 1026 tubing means higher column strength |
| Increased impact resistance |
| Increased scratch resistance |
| All stages are skive bored to meet exacting clearances |
| Closer piston tolerances |
| Compare to the competitions unfinished raw tubing |
| Dual internal piston retaining rings |
JSRUIYA Hydraulic Machinery promise:
| 1.100% quality assurance, develop and manufacture follow original ones; |
| 2. Reasonable stock and timely delivery; |
| 3. Quick response within 24 hours ; |
| 4. Long-term strong and steady supplying ability; |
| 5. One-to-one products factory.Ensure the best quality; |
| 6. The first-class logistics & Ensure that your goods arrived safely; |
| 7. Goods will Be packed safe & carefully; |
| 8. Excellent After-sales service.Track usage.Positive feedback response; |
| 9. Establish inquiry library for you, we are your professional sourcing consultant. |
Before purchase, pls contact me , we can discuss the cylinder details .
We Can Offered The Nonstandard Cylinders.JSRUIYA Hydraulic Machinery Have More Than One Decade Experience In Supplying Custom Hydraulic Cylinders With Provided Drawings Or Samples, Or If You Could Provide Following Specification:
| 1. Diameter Of Bore & Rod |
| 2. Stroke |
| 3. Mounting Style |
| 4. Mounting Distance |
| 5. Working Pressure |
| 6. Ports |
| 7. Seals |
| 8. Special Modifications |
Mounting Way:
| 1. Front And End Of Earring |
| 2. Head Fixed With Flange |
| 3. End Fixed With Flange |
| 4. Vertical To Axis Foot Type |
| 5. Middle Fixed With Pendulum Shift |
| 6 . End With Single Earring |
Quality Control:
| 1. External Inspection: Purchased Item Inspection, Outsourcing Item Inspection |
| 2. Process Inspection: First Inspection, Random Inspection, Handover Inspection |
| 3. Final Quality Inspection: External Dimensions Inspection, 100% Hydraulic Test |
| 4. Type Inspection:Every Piece Of Hydraulic Cylinder Is Tested And Will Send Out Only After They Are Pasted Each Test. |
