Mini 4G USB Dongle LTE UFI Mobile Data Network Card Wifi Hotspot Dongle
Mini 4G Dongle USB LTE Ufi Mobile Data Wireless Router Network Card Wifi Hotspot Dongle
Portable, plug and play, easy to use;
Power supply by PC/Power bank/Charging plug etc;
150M high-speed 4G Internet Support 8 connections simutaneously;
Management Web UI page;
| Model | UF1601-EN | LTE WiFi dongle |
| Chipset | Chipset | Qualcomm MSM8916 |
| Technical Standard | 4G-LTE | Up to 150 Mbps DL and 50 Mbps UL |
| 3G-UMTS | Up to 42 Mbps DL and 5.76 Mbps UL(DC-HSPA+ mode) | |
| WLAN | 802.11 b/g/n | |
| Frequency Band | FDD/TDD-LTE | B1,3,7,8,20 |
| UMTS | B1/2/4/5/8 | |
| WLAN | 2.4GHz | |
| External Interface | USB Type | Type A USB 2.0 |
| SIM/USIM Card | 2FF SIM card slot | |
| Main Features | Languages Supported | English,Chinese or more language requested |
| Operate System Supported | Win XP/ 7 /8/10, MAC OS, linux, Android | |
| Win XP/ 7 /8 /10(USB modem) | ||
| Power supply | Input | DC +5V/≥1A |
| WLAN | Frequency | 2400MHz～2483.5MHz |
| Channels | 1 ~ 13 | |
| Users | 8 | |
| Manage mode | Web UI | 192.168.43.1 |
| Antenna | Main antenna | Build-in LTE/UMTS main antenna |
| DIV antenna | Build-in LTE/UMTS antenna | |
| WLAN antenna | Build-in WiFi antenna | |
| Dimension | L * W * H | 96 * 34 * 12.5 MM |
| Standard Package Contents | LTE WIFI DONGLE | 1 |
| Quick Start Guide | 1 |
Welcome to Shenzhen Zhibotong Electronics Co., Ltd.established in 2010, located at Longhua District,
Shenzhen,China. ZBT is a manufacturer which is consist of 300 staffs, with a 30-person R & D team,
10,000 Square meters production scale. Professional in R&D and producing network devices, specially
for processing OEM/ODM. Products include openWRT wifi router,3G/4G router,Vehicles router,AP,Outdoor
CPE and LTE CPE.ZBT is also a Wi-Fi coverage service provider,provides the solution for hotel,school,
hospital,enterprise,airport and vehicle field.We have built a long term cooperation with Mediatek,Broadcom
and Qualcomm,capably offering good quality products and fast after-sale service to our clients.Till now,
ZBT's products have exported to over 30 countries and regions.Our main customers are China Mobile,
Vivacom in Bulgaria, Sprint,T-Mobile,AT&T in USA and Smart in Philippine. We also take part in different
Communication Fairs,such as MWCA in USA,Gitex in Dubai, Cebit in Germany and Computex in Taipei.
Each year, ZBT will take out more than 35% of the annual turnover as R&D funds to develop new products,
so as to satisfy clients' new coming requests.Customers' satisfaction is ZBT's continuously pursues.
ZBT warmly welcome everybody joining in and build win-win cooperation.
