MTK7621A 5G CPE Router Wifi 6 1800Mbps Dual Bands Gigabit Ports High Speed

Brief overview

Z2102AX is a 5G+WIFI6 household CPE product. It accesses the Internet through 5G dial-up, and shares the Internet through wireless WiFi 6 and 1000Mbps wired LAN.

Main Features of the Product

• MT7621A scheme, MIPS dual core CPU, main frequency up to 880MHz
• Independent WIFI6 chips, MT7905D and MT7975D, with a speed up to 1800Mbps
• The 2.4G rate is up to 573.5Mbps, and the 5.8G rate is up to 1201Mbps, collectively referred to as 1800 Mbps
• Support MU-MIMO, and WIFI modulation mode supports 1024-QAM and OFDMA
• High speed 256MB DDR3 with 16MB Nor Flash storage
• 1WAN and 3LAN, 1000M self-adaptive network interface, supporting automatic flipping (Auto MDI/MDIX),
• Built in 5G module shares 5G network to routing SOC system through 1000M network interface
• External standard SIM card (large card) interface, supporting SIM/USIM card
• With the hardware watchdog function, it can automatically restart in the extreme case of a crash
• When multiple products are used at the same time, MESH automatic networking is supported
  4 Hardware

Interface

Introduction to Indicator Functions

Hardware platform introduction

Introduction to watchdog function

When the routing system operates normally, but only the 4G/5G module dials abnormally, the routing system can control the power supply of the 4G/5G module through GPIO to automatically restart the 4G/5G module to repair the dialing exception.

When the system operates abnormally, the hardware watchdog function will restart the whole system.

5G module interface description

This product has a built-in 5G module. After the 5G module dials up to the Internet, it is converted into a 1000M network interface through the RGMII bus of the 5G module, and then connected to the routing SOC network interface to share the 5G network. In this way, the high-speed 5G network can be shared to the routing SOC to the maximum extent, and will not be limited by the USB3.0 data bus of the routing SOC, so that the 5G high-speed network cannot be fully used.
