1. Brief overview

Z2102AX-S is a 5G WIFI6 CPE product. It accesses the Internet through 5G dial-up, and shares the Internet through wireless WiFi 6 and 1000Mbps wired LAN.

2. Main Features of the 5G CPE:

• MT7621A scheme, MIPS dual core CPU, main frequency up to 880MHz
• Independent WIFI6 chips, MT7905D and MT7975D, with a speed up to 1800Mbps
• The 2.4G rate is up to 573.5Mbps, and the 5.8G rate is up to 1201Mbps, collectively referred to as 1800 Mbps
• Support MU-MIMO, and WIFI modulation mode supports 1024-QAM and OFDMA
• High speed 256MB DDR3 with 16MB Nor Flash storage
• 1WAN and 3LAN, 1000M self-adaptive network interface, supporting automatic flipping (Auto MDI/MDIX),
• Built in 5G module shares 5G network to routing SOC system through 1000M network interface
• External standard SIM card (large card) interface, supporting SIM/USIM card
• With the hardware watchdog function, it can automatically restart in the extreme case of a crash
• When multiple products are used at the same time, MESH automatic networking is supported
•
• 3.  Hardware Interface

5G module interface description

This product has a built-in 5G module. After the 5G module dials up to the Internet, it is converted into a 1000M network interface through the RGMI bus of the 5G module, and then connected to the routing SOC network interface to share the 5G network. In this way, the high-speed 5G network can be shared to the routing SOC to the maximum extent, and will not be limited by the USB3.0 data bus of the routing SOC.
