ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
1. Simply Description:
The WE5928uses the latest MT7628N wireless solution, performs better and more function. Stable wireless performance, more functions , 2.4G 300Mbps, Also support 3G&4G function.One SD card slot. Beautiful share design.It is best choice to use home,office and other engineering project.
2. Product Features:
- Support 802.11N/802.11G/802.11B network protocol, the max transmission rate could be 2.4G 300Mbps
- Support 802.113/802.11U protocol, 3* 10/100M bps Auto MDI/MDIX
- 1 Micro SD Card Slot
- Support 3G/4G
- With hardware watchdog, support redail up Internet after loosing Internet
- Preload English openwrt firmware, support flash customer's firmware
Warm Reminder
Please check the modem bands!
|
Frequency Bands |
FDD+TDD-LTE | B1/3/5/7/8/20+B38/39/40/41 |
| TDS | B34/39 | |
| WCDMA | B1/5/8 | |
| GSM | 850/900/1800 |
Specification:
| Hardware | ||
| Main Chipset | MT7628NN | |
| RAM | DDR2 64MB (MAX DDR2 128MB) | |
| SPI FLASH | 8MB (MAX 16MB) | |
| Protocol | IEEE 802.11n.IEEE 802.11g.IEEE 802.11b.IEEE 802.3u | |
| RT Power |
802.11b 18dBm±2dBm; 802.11g 15dBm±2dBm; 802.11n 15dBm±2dBm;
|
|
| Reception Sensitivity |
802.11b: -83dBm@10% PER 802.11g: -74dBm@10% PER 802.11n: -68dBm@10% PER |
|
| Work Channel | 2.4GHz choose :1-13 | |
| Wireless Rate | Max 300Mbps | |
| Work Frequency | 2.4GHz | |
| Antenna | 2* 2.4G 5dBi antenna,2*4G 5dBi antenna, 2*4G FPC antenna | |
| Interface |
2*SIM card slot 1*Micro SD card slot 1*10/100M WAN port(Auto MDI/MDIX) |
|
| LED | Power,PCIE mode ,2.4G,WAN,LAN1,LAN2,LAN3, | |
| Button | Reset/WPS | |
| Max Power consumption | < 12W | |
| Others | ||
| Work Environments |
Operating Temperature:0℃ ~ 40℃； Operating Humidity:10%~90% non-condensing |
|
| Adapter | 9V 1A | |
| Authentication | CE, FCC, RoHs | |
| Other accessories |
Power adapter
|
|
FAQ
Can you printing Customer logo on products?
Yes, we can printing your logo on products.
Do you provide PCBA board order only?
Of course, as a OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.
Can you desin products as per customer's requirements?
Yes, of course. We have our own R&D department, we have ability to design and produce at same time.
Do you....?
Maybe, why don't contact us now! Inquring us to see if we can, or if we do, to see if we can suprise you!
