Black 300Mbps CPE 3g 4g Wifi Router 5dBi Antennas 1 WAN
Price:
$22.86~$24.77/pcs
MOQ:
200pcs
Delivery Time:
3-5 working days
Brand:
ZBT
Product Description
South East Europe 3g 4g wifi router new design 4G CPE
Band&Frequency
FDD:B1/3/7/8/20/28
TDD:B38/40/41
WCDMA:B1/8
GSM:B3/8
4G router, the actual is adding a 4G dial part on the basis of the ordinary router,divided into two types of built-in and external.Built-in is a 4G module, PCB board of the built-in router, insert the SIM card on the router to achieve the reception of the base station signal to get the internet.
ZBT-WE2805-A is a 4G routing product for home used. It accesses the Internet through 4G mobile communication dial-up or 100Mbps WAN port dial-up, and then shares the wireless WiFi and internet network to user or device. And also,it can be supported wired Ethernet .Customers can be connected WAN port by wired Ethernet cable to share wireless WiFi and wired network to user or device.
Product Feature
- Adopt MT7628NN chipset, main frequency is up to 580MHZ
- Support 2.4G, rated up to 300Mbps
- Support 802.11 N/G/B protocols.
- MT7628NN chipset integrates 64MB DDR2, match with 8MB Nor Flash
- 1*WAN and 2*LAN 100Mbps adaptive network port, support automatic flip(Auto MDI/MDIX)
- Support "one-click flash mode",Long press the reset button to boot and then will enter the rescue flash mode
- Built-internal 4G module to support 3G&4G function,
- One standard SIM card slot, support SIM/USIM card
- External high gain omnidirectional antenna with 360o wireless signal
- This product supports hardware watchdog function, when the routing system fails, it will restart the device automatically.
| Network port |
1*WAN,100Mbps support automatic flip(Auto MDI/MDIX) IEEE 802.3/802.3u,802.n/g/b |
|
2*LAN,100Mbpssupport automatic flip(Auto MDI/MDIX) IEEE 802.3/802.3u,802.11n/g/b |
|
| SIM card slot | 1*SIM slot,support SIM/USIM.. |
| Power | DC5.0*2.1MM port |
| Reset button | 1* reset button |
| Antenna | 2*2.4G & 5dbi external Omnidirectional antennas |
| 2*4G 5dbi internal Omnidirectional antennas | |
| 4G module interface | It is directly SMT LCC+LGA 4G module to support 3G&4G function. |
| Processor | Adopt MT7628NN Chipset,MIPS24KEc architecture CPU,main frequency is up to 580MHZ |
| 2.4G WIFI chip | MT7628NN chipset integrates 2.4G WIFI function, rated up to 300Mbps |
| RAM | DDR2 64MB |
| FASH | Nor Flash 8MB |
| Do not support NAND Flash |
