China 4G LTE SIM Card Modem Unlocked 4G USB Dongle Pocket Hotspot 4G LTE WiFi USB for sale

4G LTE SIM Card Modem Unlocked 4G USB Dongle Pocket Hotspot 4G LTE WiFi USB

Name: 4G LTE SIM Card Modem Unlocked 4G USB Dongle Pocket Hotspot 4G LTE WiFi USB
Brand: Shenzhen Zhibotong Electronics Co., Ltd.

Price Negotiable

Price: negotiable

MOQ: 1pcs

Delivery Time: 5-8 work days

Brand: OEM/Neutral

Product Description

4G LTE SIM Card Modem Unlocked 4G USB Dongle Pocket Hotspot 4G LTE WiFi USB

Specification

Item		Description
Model	UF1601-EN	LTE WiFi dongle
Chipset	Chipset	Qualcomm MSM8916
Technical Standard	4G-LTE	Up to 150 Mbps DL and 50 Mbps UL
	3G-UMTS	Up to 42 Mbps DL and 5.76 Mbps UL(DC-HSPA+ mode)
	WLAN	802.11 b/g/n
Frequency Band	FDD/TDD-LTE	B1,3,7,8,20
	UMTS	B1/2/4/5/8 (combination depend on LTE bands)
	WLAN	2.4GHZ
External Interface	USB Type	Type A USB 2.0
	SIM/USIM Card	2FF SIM card slot
	Power button	Long press 3 seconds to power ON or OFF
	RESET button(pinhole)	Long press 3 seconds to reset to factory setting
Main Features	Form Factor	USB stick
	Visual Indicator(LED)	LED dio display working status (signal/data flow)
	Languages Supported	English,Chinese or more language requested
	Operate System Supported	Win XP/ 7 /8/10, MAC OS, linux, Android (AP mode)
	Operate System Supported	Win XP/ 7 /8 /10(USB modem )
Power supply	Input	DC +5V/≥1A
WLAN	Frequency	2400MHz～2483.5MHz
	Channels	1 ~ 13
	Users	8
Manage mode	Web UI	192.168.43.1
Antenna	Main antenna	Build-in LTE/UMTS main antenna
	DIV antenna	Build-in LTE/UMTS antenna
	WLAN antenna	Build-in WiFi antenna
Certification	ROHS	Supported
	CE	Supported
	CCC	Supported
	Other	Could be supported upon requested
Dimension	L * W * H	96 * 34 * 12.5 MM
Standard Package Contents	LTE WIFI DONGLE	1
Standard Package Contents	Quick Start Guide	1

Product Description

4G USB Dongle Specification

UF1601-EN 4G wireless UFI is a wireless communication product based on the requirement of 4G network. It can meet the requirement of stable, safe and simple internet access for small networks such as individuals, offices and families. It can also be applied in the Internet of Things communication industry to provide users with wireless long-distance data monitoring, acquisition and transmission functions.

Details Images

This device has high-efficiency 4G WIFI Internet access function. Let you travel more convenient. The equipment takes into account the fast access to the network in inconvenient wiring areas, so that users can access the Internet freely at any time and anywhere. It's easy to use and can be connected to the Internet quickly. The equipment is accessed by 4G LTE network, and the high-speed and stable network environment of the 4G LTE network ensures that the product can access the Internet more reliably. It can meet the needs of stable, safe and simple internet access for small networks such as personal office and family. It can also be used in the Internet of Things communication industry to provide users with wireless acquisition and transmission functions.
Product characteristicsSupporting Internet Access of Unicom, Telecom and Mobile Charging mode: USB 5V 1A. Supporting CAT4 protocol to support downlink 150Mbps ,Uplink 50Mbps. Provide external LED status indication, display signal state. Support 4G network access, no wiring, anytime anywhere on the Internet. Support WIFI password access. WEB management convenient and quick  Built-in all-network 4G high gain 4G antenna
