Architecture 5mm Galfan Welded Mesh Gabion

Price Negotiable
Price: $6-15/PCS
MOQ: 1 PCS
Delivery Time: within 7-10 days
Brand: KAAP
Product Description

Gabion Wall Architectural Gabion Wall Welded mesh For Argentina



About Gabion Wall



In front of the façades, we placed gabions, a device used in river engineering, that is, wire containers filled with stones. Added to the walls, they form an inert mass that insulates the rooms against heat by day and cold at night.





The gabions are filled more or less densely as needed so that parts of the walls are very impenetrable while others allow the passage of light: natural light comes into the rooms during the day and artificial light seeps through the stones at night. You could describe our use of the gabions as kind of stone wickerwork with varying degrees of transparency, more like skin than like traditional masonry.







Specifications

Size
1.0x0.3x0.3 m
Wire diameter
3.8 mm
Opening mesh
5x10 cm
Surface treatment
galvanized



Manufacturer certified according to ISO 9001
Material Highly elastic steel wire
Coating 95% zinc 5% aluminium
Material thickness: 4.5 mm
tensile strength > 450 N / mm²
Mesh width 100/100 mm, 100/50 mm




Applications
  • Mass gravity retaining walls
  • Facing units to reinforced soil walls
  • Landfill
  • Perimeter walling
  • Acoustic barriers
  • River and coastal protection
  • Reed beds
  • Abutments
  • Landscaping
  • Free standing walls
  • Temporary works



Features
1.Anti-erosion
2.Weather resistant
3.High tensile strength
4.Easily assembled

Packing

Company profile
Our factory established in 2006 year, and we have 14 years' experience in research and development, we mainly do welded gabion, weaving gabion box, welded mesh panel, steel bar grating, razor barbed wire, bird spike,chain link mesh, hexagonal wire mesh, ground staple, T/Y post, vineyard post, and other metal products, etc....and we enjoys high reputation at home and abroad, and we have professional team, we have excellent workmanship and price favorable to cooperate.
