Box Metal Stone Wall 0.3m Length Welded Mesh Gabion
Easy Installation Welded Gabion Box Metal Gabions Stone Wall for sale
1. Finishing: heavy duty galvanized or galfan galvanized
2. Surface treatment: electro galvanized, hot-dipped galvanized, pvc coated, stainless steel
3. Wire diameter: 2.7--5mm
4. Mesh size/opening: 37.5x75mm, 50x50mm, 75x75mm, 100x50mm, 100x100mm
5. Zinc coating: 40-290g/mm2
6. Application: Flood dam, dam and diversion, Prevent soil erosion, bridge protection, retaining wall, road protection
7. Feature:easy to install, beautiful structure, low cost, it is the best choice for garden decoration greening slope.
*Features:
1. Strong anti-erosion ability 2.security and stability 3.Construction is simple, ecological stone cage cage process just stone into the cage can be sealed, do not need special technology, do not need water and electricity 4.Good landscape and protection effect 5.Long service life, ecological stone cage net process life for decades, and generally do not need maintenance
Application of Easy Installation Welded Gabion Box Metal Gabions Stone Wall
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil.
Protection engineering of seaside area.
Easy Installation Welded Gabion Box Metal Gabions Stone Wall specifications as below:
|
Nominal Box sizes (m) |
Mesh size (mm) |
No. of diaphragms (no.) |
Capacity per box (m3) |
| 1.0x1.0x0.5 |
50x50
75x75
50x100
100x100 |
0 | 0.50 |
| 1.0x1.0x1.0 | 0 | 1.00 | |
| 1.5x1.0x0.5 | 0 | 0.75 | |
| 1.5x1.0x1.0 | 0 | 1.50 | |
| 2.0x1.0x0.5 | 1 | 1.00 | |
| 2.0x1.0x1.0 | 1 | 2.00 | |
| 3.0x1.0x0.5 | 2 | 1.50 | |
| 3.0x1.0x1.0 | 2 | 3.00 | |
| 4.0x1.0x0.5 | 3 | 2.00 | |
| 4.0x1.0x1.0 | 3 | 4.00 |
