GZPB370 High Speed Tablet Press Machine 380V Precision Stainless Steel Rotary Tablet Press
Price:
Welcome to consult
MOQ:
1
Delivery Time:
30-45 working days
Brand:
Tianfeng
Product Description
GZPB370 High Speed Tablet Press Machine
Purpose
This single side rotary tablet press machine converts granular materials into round, irregular, or double-side engraved tablets. Ideal for pharmaceutical, chemical, food, and electronic industries.
Features
- Stainless steel construction with fully enclosed housing. Rotary turret features hardened surface for wear resistance and complies with GMP standards.
- Organic glass windows with stainless steel door frames enhance both aesthetics and structural rigidity.
- Frequency inverter for adjustable speed. Motor mounted on base plate prevents vibration during operation.
- Intermittent automatic lubrication system for upper/lower guide rails and punches reduces wear.
- Hydraulic overload protection automatically stops machine during over-pressure to prevent punch damage.
- High-precision pressure sensor with amplifier enables reliable self-checking of tablet compression pressure. Easy-to-use weight control system with batch/individual rejection of substandard tablets.
- Customizable impeller options in forced feeder for different material requirements.
Main Technical Parameters
| Model | GZPB-26 | GZPB-32 | GZPB-40 |
|---|---|---|---|
| No. of Stations | 26 | 32 | 40 |
| Type of Tooling | D | B | BB |
| Max. Pressure (kN) | 100 | 80 | 80 |
| Max. Pre-pressure (kN) | 20 | 20 | 20 |
| Max. Tablet Diameter (mm) - Round | 25 | 18 | 13 |
| Max. Tablet Diameter (mm) - Special shaped | 25 | 19 | 16 |
| Max. Filling Depth (mm) | 16 | 16 | 16 |
| Max. Tablet Thickness (mm) | 6 | 6 | 6 |
| Upper and Lower punch Length (mm) | 133.6 | 133.6 | 133.6 |
| Upper and Lower punch diameter (mm) | 25.35 | 19 | 19 |
| Middle Mold Diameter (mm) | 38.1 | 30.16 | 24.01 |
| Middle Mold Height (mm) | 23.81 | 22.22 | 22.22 |
| Max. Tablets output (pcs/hour) | 135000 | 201000 | 252000 |
| Max. Turret Speed (1/min) | 11-87 | 11-105 | 11-105 |
| Main Motor Power (kW) | 11 | 7.5 | 7.5 |
| Height of the Machine (mm) | 1850 | 1850 | 1850 |
| Machine Floor Space (mm²) | 1200×950 | 1200×950 | 1200×950 |
| Machine Net Weight (kg) | 1700 |
Packing & Shipping
