10 layer PCB with 3oz inner copper, free-Halogen material and hard gold finger
Price:
based on your gerber files
MOQ:
1pcs
Delivery Time:
5 working days
Brand:
Linked
Product Description
Raw Material
Our Capability
| Item | Capability | Remark | ||
| Layer count | 2~30 layer | |||
| Lamination | FR-4,Aluminum Based,Copper based,High frequency plate,Heavy copper,BT,Rogers,PTFE ect | |||
| Thickness (THK) | 0.2mm≤THK≤6.0mm | |||
| Smallest hole (mm) | 0.15mm | |||
| Aspect Ratio | 13:1 | |||
| Max dimension | Single or 2-layer | 600 x 1000 mm | ||
| Multi-lyr | ≤6L | 600 x 900 mm | ||
| ≥8L | 500 x 600 mm | |||
| Gold THK | Hard Gold (u") | 50u" | ||
| Immersion Gold (u") | 4u" | |||
| Copper THK | Outer (oz) | 6oz | ||
| Inner (oz) | 6oz | |||
| Smallest trace width / space (mil) | 3/3 mil | |||
| Annual ring | Via hole | 3mil | ||
| Component hole | 6mil | |||
| Copper to edge spacing | 0.25mm | |||
| Min trace width / space (mil) | Base Copper (oz) | Min trace width / space (mil) | ||
| 0.5 | 3/3 | |||
| 1 | 4/4 | |||
| 2 | 5/5 | |||
| 3 | 7/7 | |||
| 5 | 9/9 |
|||
