TS16949 Certified Automotive Circuit Board 1.6MM 2OZ Reach Compliant
OEM Automotive PCB TS16949 Certified 1.6MM 2OZ Green Solder Mask Reach Compliant PCB
Linked Electronics is a China based PCB manufacturer with full in house manufacturing capabilities. We have been in business since 1998 specializing in quick turn, high quality custom PCB fabrication. For more than two decades Linked has been a leading PCB manufacturer in China specializing in Quick-turn Printed Circuit Boards.
Linked has been supplying highly qualitative, economical and PCBs to the electronics industry in China and globally since 1998. We also offer contract assembly and parts assembly as a part of our turnkey solution to customers.
FAQ
Q1.What is needed for PCB or PCBA quotation?
· PCB: Gerber file or other PCB files and Spec (material,surface finish treatment, copper thickness,board thickness,Quantity ,...)
· PCBA: PCB file, BOM, Pick and Place Files
Q2. What file formats do you accept for PCB PCBA production?
· Gerber file: CAM350 RS274X Format
· PCB file: Protel 99SE, P-CAD 2001 PCB, Eagle, Altium
· BOM: Excel (PDF,word,txt)
Q3. Will you discose the file to any other people.
NDA can be signed. Your files will NOT sent to any third party. We protect the intellectual property for our customers in the whole process.
Q4. What’s the MOQ?
Linked Electronics don’t have any minimum lot requirements, so you never have to buy more than what you need.
Our Capability
| Item | Capability | Remark | ||
| Layer count | 2~30 layer | |||
| Lamination | FR-4,Aluminum Based,Copper based,High frequency plate,Heavy copper,BT,Rogers,PTFE ect | |||
| Thickness (THK) | 0.2mm≤THK≤6.0mm | |||
| Smallest hole (mm) | 0.15mm | |||
| Aspect Ratio | 13:1 | |||
| Max dimension | Single or 2-layer | 600 x 1000 mm | ||
| Multi-lyr | ≤6L | 600 x 900 mm | ||
| ≥8L | 500 x 600 mm | |||
| Gold THK | Hard Gold (u") | 50u" | ||
| Immersion Gold (u") | 4u" | |||
| Copper THK | Outer (oz) | 6oz | ||
| Inner (oz) | 6oz | |||
| Smallest trace width / space (mil) | 3/3 mil | |||
| Annual ring | Via hole | 3mil | ||
| Component hole | 6mil | |||
| Copper to edge spacing | 0.25mm | |||
| Min trace width / space (mil) | Base Copper (oz) | Min trace width / space (mil) | ||
| 0.5 | 3/3 | |||
| 1 | 4/4 | |||
| 2 | 5/5 | |||
| 3 | 7/7 | |||
| 5 | 9/9 | |||
