Custom Multilayer PCB Board 1.6mm 2oz All Layer IPC Class 3 Standard High CTI
Custom Multilayer PCB Board 1.6mm 2oz All Layer IPC Class 3 Standard High CTI
Linked Electronics is a China based PCB manufacturer with full in house manufacturing capabilities, which specialized in high-mix, prototype, low volume and quick turn PCBs.
If you are currently tooled for a board elsewhere and would like to investigate the possibility of moving the business to us.Please mention this when you send enquiry and we will offer FREE OF CHARGE TOOLING
Look forward to working with you!
PCB Specification
| Product Name | Electronic Custom PCB Printed Circuit Board PCBA Design |
| Type | Rigid |
| Material | FR4, CEM1, CEM3, High Frequency Board, |
| Layer | 1,2,4,6...32 Layer |
| Shape | Rectangular, Round, Slots, Cutouts, Complex, Irregular |
| Cutting | Shear, V-score, Tab-routed |
| Board Thickness | 0.2-6mm, regular 1.6mm |
| Copper Thickness | 0.5-4oz, regular 1oz |
| Solder Mask | Green, Red, Blue, Yellow, etc. |
| Silk Screen | White, Black, etc. |
| Silk Screen Min Line Width | 0.006" or 0.15mm |
| Min Trace/Gap | 0.1mm or 4mils |
| Min Drill Hole Diameter | 0.01",0.25mm or 10mils |
| Surface Finish | HASL, ENIG, OSP, etc. |
Raw Material Supplier
| Main material and supplier | |
| Raw Material | Specification |
| FR4 | ShengYi |
| ITEQ | |
| Isola | |
| Copper foil | Mitsui Kinzoku |
| Taiwan Changchun | |
| Shangdong Jinbao | |
| Prepreg | ShengYi |
| HongRen | |
| Soldermask | TaiYo |
| GuangXin | |
| Bst Checmical | |
| Greencure (Huizhou) | |
| Chemical | MaxDermid Chemical |
| Rohm and Haas | |
| Copper ball | Chengan Copper Industry |
| Tin bar | Sheng Nan Technology |
Industries / markets that Linked served
Industrial, Automotive, and Commercial: With over 2 decades of PCB expertise, we have a huge array of customers that are leaders in their commercial and industrial niches. With our high-technology PCB capabilities, we have created long-lasting partnerships throughout various industries
Medical and Bio-medical: When strict quality standards are required, various niche medical device companies and medical equipment OEM manufacturers depend on us for their medical PCB and PCBA manufacturing.
Students and Hobbyist: With our straightforward and no hidden cost PCB pricing, we have earned the trust of multiple educational institutions from around the world. When students need affordable printed circuit boards for their various university projects, they can rely on Linked Electronics.
Main Industries that We Served
