Common Rail Fuel Injection Pump Repair Kit Adjusting Shims B24 Washer Gasket
Adapter injector models:Denso φ1.7 φ3.95
095000-5212/5226/5471/5511/6353/6593/6700/6791/8100/5600/5650/(16600 EB300/16600 BN 821)/5801/7030
07L 0127 9709500-890
Remarks: B24 has 26 models, each 5pcs, totally 130pcs.
|
Name |
Model | Size(mm) | Step Model | Step Size(mm) | Injector No. |
| Bushing Calibrate Shim Suite | B11 | 0.9-1.5 | B11A | 0.9-1.0 | Bosch φ19 φ22 |
| B11B | 1.0-1.1 | ||||
| B11C | 1.1-1.2 | ||||
| B11D | 1.2-1.3 | ||||
| B11E | 1.3-1.4 | ||||
| B11F | 1.4-1.5 | ||||
| Bushing Calibrate Shim Suite | B12 | 0.9-1.5 | B12A | 0.9-1.0 | Bosch φ18 φ22 |
| B12B | 1.0-1.1 | ||||
| B12C | 1.1-1.2 | ||||
| B12D | 1.2-1.3 | ||||
| B12E | 1.3-1.4 | ||||
| B12F | 1.4-1.5 | ||||
| Bushing Calibrate Shim Suite | B13 | 0.9-1.96 | B13A | 1.2-1.96 | Bosch φ2.3 φ4.2 |
| B13B | 0.9-1.9 | ||||
| Bushing Calibrate Shim Suite | B14 | 0.9-1.86 | B14A | 1.6-1.8 | Bosch φ3.4 φ5.5 |
| B14B | 1.2-1.86 | ||||
| B14C | 0.9-1.9 | ||||
| The First Generation Plunger Calibration Kit | B15 | 8.3-8.7 | B15A | 8.3-8.4 | Bosch φ5.76 |
| B15B | 8.4-8.5 | ||||
| B15D | 8.5-8.6 | ||||
| B15E | 8.6-8.7 | ||||
| The Second Generation Plunger Calibration Kit | B16 | 0.9-1.3 | B16A | 0.9-1.0 | Bosch φ2.28 |
| B16B | 1.0-1.1 | ||||
| B16D | 1.1-1.2 | ||||
| B16E | 1.2-1.3 | ||||
| Bushing Calibrate Shim Suite | B17A | 1.2-1.9 | Bosch φ2.3 φ4 | ||
| Bushing Calibrate Shim Suite | B21 | 1.0-2.5 | Denso φ3.5 φ6.8 | ||
| Bushing Calibrate Shim Suite | B22 | 0.98-1.44 | Bosch φ4.8 φ7.7 |
For other models, you can check in the alog:
Product series:
1.Diesel injection pump test bench
2.Common rail injector and pump test bench
3.Full function test bench
4.Common rail/HEUI /EUI/EUP/Mechanical pump tools
5.Head rotor: (Isuzu, Toyota, Mitsubishi, Iveco, Fiat, etc.)
6.Nozzle:(Type: DN_SD, DNOPDN, S, SN, P, PN.etc.)
7.Repair kit (VE pump, Lucas, etc.)
8.Delivery valve: (type A, P, etc.)
9.Common rail control valve: (Bo-sch, Den-so, Del-phi)
10.Diesel fuel injectors (Bo-sch, Den-so, Del-phi)
1. 7*24 online service;
2. Fast delivery;
3. OEM service;
4. You can get all products in one place here.
The main products include diesel injector, injection pump, Common Rail, ECU, and nozzle, valve, sensor, plunger, head rotor, repair kit.
They are produced by China factory, or world-famous manufacturer such as Bosch, Denso, Delphi, VDO, , Volvo, Isuzu, Yanmar.
We sincerely welcome friends from all over the world and provide best products and service. If you have any question, please feel free to contact us. Thank you!
