Non Metallic Slurry 150RPM 3500ml Cup Vacuum Planetary Mixer
3500ml x2 Cups Planetary Centrifugal Vacuum Mixer Non Metallic Slurry Use
Product specification
| SPECIFICATION FOR ZYMC-7000VS PLANETARY MIXER | |||
| Container Capacity | 3500ml*2cups | Working Capacity | 1750ml*2cups |
| Revolution Speed | 150-1000RPM | Rotation Speed | Adjustable |
| Protection | Door cover, Vibration, Over load | Operation Type | Human-machine Interaction Mode |
| Multi-parameter Group | 0-5group, 3part/group | Power/Voltage | 7.5KW/380V |
| Size | L1000*W800*H930mm | N.W. | 255+75KG |
Main feature
1. Double cups
2. Vacuum is included
3. Multi-step parameter
4. Various adapters, customizable
5. Suitable for research and development, volume production
6. Unlimited scale of revolution and rotation, wide range applicable scope
7. Vacuum: 80L/min, approx.-100kpa (when the altitude is zero metres)
8. Standard accessories:Cup:6pcs；Transmission belt:1 pcs(backup)
Application
Our planetary mixer is widely used for semiconductor, touch screen, LED, photovoltaic, new materials and chemistry industry.
Like Epoxy Resin, Adhesive Agent, Silver Paste, Soldering Paste, LED Phosphor Material, Carbon Nanotube and so on.
Especially for high viscosity and good fineness products.
About US
ZYE is a leading precision equipment manufacturer focusing on planetary mixing and high-end three-roll-mill in China,and is a national high-tech enterprise as well.
We are committed to providing the best solution of mixing, degassing and grinding solution for every segment of material field.
Package&Shipping
-Packing: 1 set, wooden box
-Outside package: Standard export wooden
-Inner package: Shock-proof plastic film
