350ml*2 125KG Planetary Centrifugal Vacuum Mixer Human-machine Interaction Mode

The planetary centrifugal vacuum mixer is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste.

Vacuum type defoaming (suitable for materials with relatively high viscosity)
Defoaming takes place on the basis of the following principles:
1. When viscosity is high, bubble rising speed is low, and bubbles are carried to the surface by convection of the material.
2. Bubbles expand due to reduced pressure and are destroyed. Solvent gas bubbles also appear.
3. Small bubbles are also destroyed on the liquid surface by shearing force due to "rotation".

Product specification

Main feature

1. Double cups

3. Stabilisation, durable

4. Multi-step parameter

5. Variousadapters, customizable

6. Unlimited scale of revolution and rotation; wide range applicable scope

7. Standard accessories:Cup:6pcs；

8.Compliance:CE Certified

Transmission belt:1 pcs(backup)

Product description:

1: The material is evacuated while rotating and revolving in the container, and the mixing, dispersion and defoaming of high-viscosity materials can be realized in a few minutes.

2: Spiral bevel gear transmission: its stable and low-noise mechanical transmission. The machine has a low failure rate and a long life.

3: The overall boom is easy to maintain.

4: Rodless mixing is pollution-free and does not damage the material properties.

5: Standard machine 0~2000RPM, high speed and high efficiency. Special requirements can be customized up to 3000RPM machine.

6: Various fixtures can be customized according to customer requirements to meet customers' requirements for direct use of different packaging.

Application

Applicable industries: semiconductor lighting (LED), photovoltaics, lithium batteries, capacitors, fine chemicals, etc.

Applicable materials: various particles (fluorescent powder, chemical powder, metal micro particles, etc.), liquid glue (silica gel, various adhesives, conductive glue, printing ink, etc.), metal paste (silver paste, aluminum paste, etc.).

Our planetary mixer is widely used for semiconductor, touch screen, LED, photovoltaic, new materials and chemistry industry.

Like Epoxy Resin, Adhesive Agent, Silver Paste, Soldering Paste, LED Phosphor Material, Carbon Nanotube and so on.

Especially for high viscosity and good fineness products.
