Pharmaceutical Filtration 50 Micron 316L Ss Sintered Filter Cartridge
Pharmaceutical Filtration 50 Micron 316L Ss Sintered Filter Cartridge
Stainless steel 316L sintered mesh filter description
Sintered filter elements made of stainless steels, bronze, nickel based alloys, titanium and several special alloys can be manufactured seamless up to 1,600 mm and length and 320 mm OD.
Stainless steel 316L sintered filter Specification
|
Product Details
|
material | SS316L Sintered wire mesh |
| Filter diameter | Ø60mm | |
| filtration rate | 50um | |
| end caps | 222-swing, 226-swing, SOE/DOE/M series/BSP series/ NPT series | |
| filtration media | sintered metal wire mesh | |
| O-ring / Gasket | PTFE/ EPDM/ Nitrile/silicone/ Viton | |
| filtration Area | 0.04m²-0.75m² | |
| working tem | 450℃ | |
| working pressure | 1.5-2.5mpa | |
| pressure drop | 0.6-1.0mpa | |
| application |
*polyester, pre polymer, film filtration *lithium battery, slurry filtration, paint, glue filtration *gas, steam filter, high temperature liquid, viscous liquid filtration *food and beverage filtration *pharmaceutical filtration |
|
| welding | argon ARC welding, spot welding, laser welding, plasma welding | |
| method operation: | assembled in filter housing | |
|
characteristics: |
* high flow, high precision * high porosity, permeability, pressure drop very low * excellent mechanical strength, resistance to high pressure up to 200Kg * easy to clean, back pulsing * corrosion resistance, high temperature resistance * good processing performance, folding, welding, adhesive * design flexibility |
| Service | OEM and design department |
*common size,
*customerized size
* design make drawing |
| sales team |
fast reply in 24hours |
|
| quality department | Bubble point test + PMI chemical material composition test | |
| quality warranty | 1 Year for machinery warranty | |
| Shipment way |
* by air, *by international express, * by sea *by train |
|
|
Package way |
plastic cushion film + wooden case |
|
Other material and size are also available
- Material: black wire mesh, SS201, SS304, SS310, SS316, SS316L, SS904, SS904L, Duplex 2205, Duplex2207, Hastelloy C-276, Monel 400, Inconel600, Inconel625, Inconel825
- Filter media: sintered wire mesh, pleated filter mesh, pleated sintered fiber felt
- Filter diameter: 1.38inch, 2.36inch, 2.5inch, 3inchFilter length:5inch, 10inch, 20inch, 30inch, 40inch
- Filtration rate: 1um-200um
